Airtac SAUJ100 Adjustable Cylinder SAUJ100X100-30
2. Features specially-shaped bidirectional piston sealing structure with integrated oil reservoir, ensuring compact dimensions;
3. Constructed with milled cross-shaped aluminum tubing (rodless design) offering superior corrosion resistance, integrated sensor mounting grooves for enhanced accessibility;
4. Compact length compared to ISO15552 standard cylinders of equivalent bore size within SAU series;
5. Precision-engineered adjustable cushioning mechanism for smooth operation;
6. Mounting accessories compatible with SC series cylinders;
7. High-temperature resistant seals (operating range: 0-150°C) for extreme environment applications.
Category: Standard Cylinders | Brand: AirTAC | Series: SAUJ100 Adjustable Cylinder
AirTAC SAUJ100X100-30 Adjustable Cylinder Specifications
- Model: SAUJ100X100-30
- Type: Double-acting adjustable cushioning cylinder
- Bore size: Ø100mm
- Stroke: 100mm
- Operating pressure: 0.1-0.9 MPa
- Piston speed: 50-1000mm/s
- Cushion adjustment: 30° rotation range
- Mounting type: Standard MF1 front flange
- Rod end thread: M20×1.5
- Operating temperature: -20℃ to 80℃
- Seal material: NBR (nitrile butadiene rubber)
- Weight: 3.5kg (excluding accessories)
- Dimensions: 300mm(L) × 125mm(W) × 125mm(H)
- ISO standard: 15552 compliant
Precision-engineered adjustable stroke cylinder featuring progressive cushioning control through 30° rotary adjustment. The anodized aluminum construction ensures corrosion resistance, while the dual piston seals provide leak-proof operation. Includes magnetic piston for position sensing compatibility.
- Packaging line pressure control systems
- Automated material handling equipment
- Press machine force regulation
- Automotive assembly positioning devices
- Palletizing robot end effectors
Installation note:
Adjust cushion force gradually while observing movement.
Use locknut (included) after final adjustment. Lubricate with ISO VG32
hydraulic oil before initial operation. Maintain 0.3mm minimum clearance
between magnetic sensor and cylinder body.
| Property | Property Value |
|---|---|
| sku | SAUJ100X100-30 |
| Adjustable Stroke | 30mm |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT 1/2 |
| Magnet | Non-magnetic |
| Bore Diameter | 100mm |
| Stroke | 100mm |
