Airtac SAUJ100 Adjustable Cylinder SAUJ100X100-40
2. Features specially-shaped bidirectional piston sealing structure with integrated oil reservoir, ensuring compact dimensions;
3. Constructed with milled cross-shaped aluminum tubing (rodless design) offering superior corrosion resistance, integrated sensor mounting grooves for enhanced accessibility;
4. Compact length compared to ISO15552 standard cylinders of equivalent bore size within SAU series;
5. Precision-engineered adjustable cushioning mechanism for smooth operation;
6. Mounting accessories compatible with SC series cylinders;
7. High-temperature resistant seals (operating range: 0-150°C) for extreme environment applications.
Category: Standard Cylinders | Brand: AirTAC | Series: SAUJ100 Adjustable Cylinder
AirTAC SAUJ100X100-40 Adjustable Cylinder Specifications
- Model: SAUJ100X100-40
- Type: Double-acting adjustable stroke cylinder
- Bore size: 40mm
- Stroke: 100mm (adjustable)
- Operating pressure: 0.15–0.8 MPa
- Cushioning: Adjustable pneumatic cushion (both ends)
- Mounting style: Square flange (ISO/VDI standard)
- Port size: PT1/4 (G1/8 optional)
- Temperature range: -20℃ to 80℃
- Material: Aluminum alloy barrel, hard anodized piston rod
- Seal material: NBR (nitrile rubber)
- Weight: 1.8kg ±5%
- Dimensions: 200mm(L) × 80mm(W) × 80mm(H)
- Rod diameter: 16mm (chrome-plated)
- Max theoretical thrust: 502N @0.63MPa
- Lubrication: Pre-lubricated (optional oil-free operation)
Precision stroke-adjustable cylinder featuring micrometer-style stroke adjustment mechanism (±0.5mm repeatability). Integrated shock absorption system with 5-stage cushion control prevents end-impact damage. Corrosion-resistant construction with IP54 protection rating ensures reliable performance in dusty environments.
- Precision positioning in semiconductor handling equipment
- Variable height adjustment for packaging machinery
- Clamping force control in CNC fixtures
- Material feeding systems with variable stroke requirements
- Automated assembly line stopper mechanisms
Installation tip:
Always lock adjustment screws with 1.2-1.5N·m torque after setting stroke.
For vertical mounting, install air vents upward. Lubricate guide shafts monthly
with ISO VG32 hydraulic oil in high-cycle applications (>500 cycles/day).
| Property | Property Value |
|---|---|
| sku | SAUJ100X100-40 |
| Adjustable Stroke | <40mm> |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT 1/2 |
| Magnet | Non-magnetic |
| Bore Diameter | 100mm |
| Stroke | 100mm |
