Airtac SAUJ100 Adjustable Cylinder SAUJ100X100-40S
2. Features specially-shaped bidirectional piston sealing structure with integrated oil reservoir, ensuring compact dimensions;
3. Constructed with milled cross-shaped aluminum tubing (rodless design) offering superior corrosion resistance, integrated sensor mounting grooves for enhanced accessibility;
4. Compact length compared to ISO15552 standard cylinders of equivalent bore size within SAU series;
5. Precision-engineered adjustable cushioning mechanism for smooth operation;
6. Mounting accessories compatible with SC series cylinders;
7. High-temperature resistant seals (operating range: 0-150°C) for extreme environment applications.
Category: Standard Cylinders | Brand: AirTAC | Series: SAUJ100 Adjustable Cylinder
AirTAC SAUJ100 Adjustable Stroke Air Cylinder SAUJ100X100-40S Technical Details
- Full model designation: SAUJ100X100-40S
- Bore size: Φ100mm
- Stroke length: 100mm (adjustable)
- Operating pressure: 0.05-1.0 MPa
- Cushion type: Rubber bumper + adjustable hydraulic shock absorber
- Mounting style: MF1 (Standard front flange)
- Port size: Rc1/4 (NPT1/4 optional)
- Piston speed: 50-1000mm/s
- Ambient temperature: -20℃ to 80℃
- Main materials: Aluminum alloy barrel, CRCA piston rod
- Rod end type: Female thread M20×1.5
- Weight: 5.8kg (without accessories)
- Dimensions: 325mm(L) × 125mm(W) × 125mm(H)
- Seal material: Polyurethane (NBR optional)
- ISO standard: 15552 compliant
- Max thrust: 785N @0.63MPa
Heavy-duty adjustable stroke cylinder with precision position locking mechanism. Features dual cushioning system with 270° adjustable needle valve for smooth end-of-stroke deceleration. Anti-rotation design maintains orientation stability during partial stroke operations. Integrated mounting slots allow direct installation without additional brackets.
- Variable height work platforms in automotive assembly
- Press machine stroke adjustment systems
- Packaging line product height detection mechanisms
- Plastic injection molding ejector stroke control
- Warehouse stacking position fine-tuning
Maintenance tip:
Lubricate piston rod weekly with ISO VG32 hydraulic oil. When adjusting stroke length,
always loosen the locknut before rotating adjustment screw. Maximum allowable side load: 150N.
| Property | Property Value |
|---|---|
| sku | SAUJ100X100-40S |
| Adjustable Stroke | <40mm> |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT 1/2 |
| Magnet | S-Magnetic |
| Bore Diameter | 100mm |
| Stroke | 100mm |
