Airtac SAUJ100 Adjustable Cylinder SAUJ100X100-50
2. Features specially-shaped bidirectional piston sealing structure with integrated oil reservoir, ensuring compact dimensions;
3. Constructed with milled cross-shaped aluminum tubing (rodless design) offering superior corrosion resistance, integrated sensor mounting grooves for enhanced accessibility;
4. Compact length compared to ISO15552 standard cylinders of equivalent bore size within SAU series;
5. Precision-engineered adjustable cushioning mechanism for smooth operation;
6. Mounting accessories compatible with SC series cylinders;
7. High-temperature resistant seals (operating range: 0-150°C) for extreme environment applications.
Category: Standard Cylinders | Brand: AirTAC | Series: SAUJ100 Adjustable Cylinder
AirTAC SAUJ100X100-50 Adjustable Stroke Cylinder Specifications
- Model: SAUJ100X100-50
- Type: Double-acting adjustable stroke cylinder
- Bore size: Ø100 mm
- Standard stroke: 100 mm
- Adjustment range: 0-50 mm (external mechanical stop)
- Operating pressure: 0.15–0.8 MPa
- Temperature range: -20℃ to 80℃
- Cushioning: Adjustable air cushion (both ends)
- Mounting style: Basic type (MF1) with front/rear threaded mounting
- Port size: G1/2 (ISO standard)
- Piston rod material: Chrome-plated carbon steel
- Tube material: Aluminum alloy (hard anodized)
- Seal material: NBR (nitrile rubber)
- Weight: 3.5 kg (without accessories)
- Dimensions: 250mm(L) × 120mm(W) × 120mm(H) (max extended length)
Industrial-grade adjustable stroke cylinder featuring a unique mechanical stop mechanism for precise stroke adjustment (±0.5mm repeatability). The dual-chamber design maintains full torque throughout adjustment range. Includes wear-resistant scraper seal for particle protection. Requires 40μm filtered air with ISO VG32 lubricator oil recommended.
- Press machine stroke compensation systems
- Variable height material handling platforms
- Automated welding positioners with Z-axis adjustment
- Plastic injection molding ejector mechanisms
- Textile machinery tension control systems
Adjustment procedure:
Loosen lock nut → Rotate adjustment screw (1 full turn = 2mm stroke change) →
Re-tighten to 15N·m torque. Perform adjustments under depressurized condition.
| Property | Property Value |
|---|---|
| sku | SAUJ100X100-50 |
| Adjustable Stroke | <50mm> |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT 1/2 |
| Magnet | Non-magnetic |
| Bore Diameter | 100mm |
| Stroke | 100mm |
