Airtac SAUJ100 Adjustable Cylinder SAUJ100X100-75
2. Features specially-shaped bidirectional piston sealing structure with integrated oil reservoir, ensuring compact dimensions;
3. Constructed with milled cross-shaped aluminum tubing (rodless design) offering superior corrosion resistance, integrated sensor mounting grooves for enhanced accessibility;
4. Compact length compared to ISO15552 standard cylinders of equivalent bore size within SAU series;
5. Precision-engineered adjustable cushioning mechanism for smooth operation;
6. Mounting accessories compatible with SC series cylinders;
7. High-temperature resistant seals (operating range: 0-150°C) for extreme environment applications.
Category: Standard Cylinders | Brand: AirTAC | Series: SAUJ100 Adjustable Cylinder
AirTAC SAUJ100X100-75 Adjustable Cylinder Specifications
- Model: SAUJ100X100-75
- Type: Double-acting adjustable stroke cylinder
- Bore size: Ø100mm
- Standard stroke: 100mm
- Adjustment range: 75mm (25-100mm stroke adjustment)
- Operating pressure: 0.1–0.9 MPa
- Temperature range: -20℃ to 80℃
- Cushioning: Adjustable pneumatic cushion
- Mounting style: MF1 front flange with integrated mounting holes
- Port size: G1/2 (BSPP thread)
- Rod end: External M30×1.5 thread
- Material: Aluminum alloy barrel, chrome-plated piston rod
- Seal material: NBR (nitrile rubber)
- Weight: 3.5kg (without accessories)
- Dimensions: 250mm(L) × 125mm(W) × 125mm(H) (retracted position)
- Protection rating: IP54
- Lubrication: Required (ISO VG32 or equivalent)
High-precision adjustable stroke cylinder featuring mechanical stroke adjustment lock mechanism with position indicator. The dual-scale marking system (metric/imperial) enables quick visual verification. Anti-rotation design maintains orientation during operation, with hardened guide rings for side load resistance.
- Variable height work platforms in assembly lines
- Press tooling with depth control requirements
- Adjustable clamping fixtures for CNC machining
- Material handling systems requiring stroke customization
- Packaging machine product height compensation
Installation note:
Use alignment jigs during mounting to ensure parallel installation.
Perform stroke adjustment only in depressurized state. Apply thread
sealant to port connections (PTFE tape not recommended). Lubricate
piston rod weekly in high-cycle applications.
| Property | Property Value |
|---|---|
| sku | SAUJ100X100-75 |
| Adjustable Stroke | 75mm |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT 1/2 |
| Magnet | Non-magnetic |
| Bore Diameter | 100mm |
| Stroke | 100mm |
