Airtac SAUJ100 Adjustable Cylinder SAUJ100X100-75S
2. Features specially-shaped bidirectional piston sealing structure with integrated oil reservoir, ensuring compact dimensions;
3. Constructed with milled cross-shaped aluminum tubing (rodless design) offering superior corrosion resistance, integrated sensor mounting grooves for enhanced accessibility;
4. Compact length compared to ISO15552 standard cylinders of equivalent bore size within SAU series;
5. Precision-engineered adjustable cushioning mechanism for smooth operation;
6. Mounting accessories compatible with SC series cylinders;
7. High-temperature resistant seals (operating range: 0-150°C) for extreme environment applications.
Category: Standard Cylinders | Brand: AirTAC | Series: SAUJ100 Adjustable Cylinder
AirTAC SAUJ100 Adjustable Cylinder SAUJ100X100-75S Technical Details
- Model Code: SAUJ100X100-75S
- Type: Double-acting adjustable stroke cylinder
- Bore size: Ø100mm
- Stroke: 100mm (adjustable)
- Operating pressure: 0.05-1.0 MPa
- Operating temperature: -20℃ to 80℃
- Cushioning: Adjustable rubber buffer + external stopper
- Port size: Rc1/4 (G1/4 optional)
- Mounting style: Basic type (MF) with front flange
- Rod end: Female thread M20×1.5
- Piston material: Aluminum alloy with hard anodizing
- Rod material: Stainless steel (SUS304)
- Seal type: NBR seals with wear ring
- Weight: 2.45kg (excluding accessories)
- Dimensions: 300mm(L) × 112mm(W) × 112mm(H)
- Max speed: 500mm/s
- Lubrication: Pre-lubricated (Oil-free operation possible)
High-precision adjustable stroke cylinder featuring dual-position locking mechanism with ±0.5mm repeatability. The 75S variant includes reinforced mounting brackets and anti-rotation guide for vertical applications. Integrated magnet for position sensing compatibility. Requires 5μm filtered air with ISO 8573-1:2010 [3:4:3] class.
- Press machine stroke adjustment systems
- Automated welding positioners
- Die-casting mold height calibration
- Textile machinery tension control
- Semiconductor wafer handling robots
Installation guidelines:
Maintain 0.05-0.15mm alignment tolerance during mounting. For vertical installations exceeding 45° angle,
use auxiliary support brackets (sold separately). Lubricate sliding surfaces with ISO VG32 hydraulic oil
if operating below -10℃.
| Property | Property Value |
|---|---|
| sku | SAUJ100X100-75S |
| Adjustable Stroke | 75mm |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT 1/2 |
| Magnet | S-Magnetic |
| Bore Diameter | 100mm |
| Stroke | 100mm |
