Airtac SAUJ100 Adjustable Cylinder SAUJ100X1000-10
2. Features specially-shaped bidirectional piston sealing structure with integrated oil reservoir, ensuring compact dimensions;
3. Constructed with milled cross-shaped aluminum tubing (rodless design) offering superior corrosion resistance, integrated sensor mounting grooves for enhanced accessibility;
4. Compact length compared to ISO15552 standard cylinders of equivalent bore size within SAU series;
5. Precision-engineered adjustable cushioning mechanism for smooth operation;
6. Mounting accessories compatible with SC series cylinders;
7. High-temperature resistant seals (operating range: 0-150°C) for extreme environment applications.
Category: Standard Cylinders | Brand: AirTAC | Series: SAUJ100 Adjustable Cylinder
AirTAC SAUJ100X1000-10 Adjustable Stroke Cylinder Specifications
- Model: SAUJ100X1000-10
- Bore size: Ø100mm
- Stroke: 1000mm (adjustable in 1mm increments)
- Operating pressure: 0.05–1.0 MPa
- Cushioning: Adjustable air cushion at both ends
- Mounting type: MF1 (basic front flange)
- Rod end type: External thread M45×2
- Ambient temperature: -20℃ to 80℃
- Piston speed: 50–700 mm/s
- Seal material: Polyurethane (NBR optional)
- Weight: 18.5kg (excluding accessories)
- Dimensions: 1180mm(L) × 128mm(W) × 128mm(H)
- Port size: G3/8 (standard), optional NPT1/2
- Protection rating: IP54 (standard wiper design)
Heavy-duty adjustable stroke cylinder with precision positioning capability, featuring a double-acting design and magnetic piston for sensor compatibility. The chrome-plated piston rod and anodized aluminum barrel ensure corrosion resistance in harsh environments. Includes stroke adjustment lock nuts and position indicator scales.
- Die casting machine ejection systems
- Automotive assembly line positioning arms
- Paper roll handling equipment
- Plastic injection molding clamp adjustment
- Steel coil feeding mechanisms
Installation note:
Always perform stroke calibration at 0.3-0.5 MPa air pressure.
Lubricate with ISO VG32 hydraulic oil if using non-lubricated air.
Allow 50mm clearance behind flange for maintenance access.
| Property | Property Value |
|---|---|
| sku | SAUJ100X1000-10 |
| Adjustable Stroke | <10mm> |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT 1/2 |
| Magnet | Non-magnetic |
| Bore Diameter | 100mm |
| Stroke | <1000mm> |
