Airtac SAUJ100 Adjustable Cylinder SAUJ100X1000-100
$398.70
Regular price
$406.20
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
SAUJ100X1000-100
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
1. Compliant with enterprise-standard cylinder specifications;
2. Features specially-shaped bidirectional piston sealing structure with integrated oil reservoir, ensuring compact dimensions;
3. Constructed with milled cross-shaped aluminum tubing (rodless design) offering superior corrosion resistance, integrated sensor mounting grooves for enhanced accessibility;
4. Compact length compared to ISO15552 standard cylinders of equivalent bore size within SAU series;
5. Precision-engineered adjustable cushioning mechanism for smooth operation;
6. Mounting accessories compatible with SC series cylinders;
7. High-temperature resistant seals (operating range: 0-150°C) for extreme environment applications.
Category: Standard Cylinders | Brand: AirTAC | Series: SAUJ100 Adjustable Cylinder
Maintenance tip:
Relubricate every 50km of cumulative travel using AirTAC SPL-2 grease.
Always lock adjustment bolts with 4.5-5.5Nm torque after stroke setting.
2. Features specially-shaped bidirectional piston sealing structure with integrated oil reservoir, ensuring compact dimensions;
3. Constructed with milled cross-shaped aluminum tubing (rodless design) offering superior corrosion resistance, integrated sensor mounting grooves for enhanced accessibility;
4. Compact length compared to ISO15552 standard cylinders of equivalent bore size within SAU series;
5. Precision-engineered adjustable cushioning mechanism for smooth operation;
6. Mounting accessories compatible with SC series cylinders;
7. High-temperature resistant seals (operating range: 0-150°C) for extreme environment applications.
Category: Standard Cylinders | Brand: AirTAC | Series: SAUJ100 Adjustable Cylinder
AirTAC SAUJ100 Adjustable Stroke Cylinder SAUJ100X1000-100 Specifications
- Model Code Breakdown: SAUJ100-X1000-100
- SAUJ: Adjustable stroke cylinder series
- 100: Bore size 100mm
- X1000: Maximum stroke length 1000mm
- -100: Stroke adjustment mechanism variant
- Bore diameter: Ø100mm ±0.1mm
- Stroke range: 50-1000mm (mechanically adjustable)
- Operating pressure: 0.05-1.0 MPa
- Cushioning: Adjustable elastic buffer + shock absorber
- Ambient temperature: -20℃ to 80℃
- Mounting style: Basic type (no pre-mounted brackets)
- Port size: G1/2 (BSPP thread)
- Piston material: Anodized aluminum alloy
- Rod material: Chrome-plated steel (Cr-Mo)
- Seal type: HNBR with wear-resistant ring
- Weight: 11.8kg (dry, without accessories)
- Dimensions (L×W×H):
- Retracted: 1230mm × 142mm × 142mm
- Extended: 2230mm × 142mm × 142mm
- ISO standard: 15552 compliant
Heavy-duty adjustable stroke cylinder with precision ground rod and multi-layer sealing system. Features dual-position locking mechanism for stroke adjustment via external hex bolts (10mm wrench required). Includes built-in magnet for position sensing compatibility. Requires 5μm filtered air with lubrication (ISO VG32 recommended).
Industrial Applications:
- Variable height positioning in automotive assembly jigs
- Material handling with adjustable gripping depth
- Plastic injection molding ejector systems
- Large-format printing press paper feed mechanisms
- Solar panel production line alignment devices
Maintenance tip:
Relubricate every 50km of cumulative travel using AirTAC SPL-2 grease.
Always lock adjustment bolts with 4.5-5.5Nm torque after stroke setting.
Note: Requires minimum 150mm free space at rod end for full adjustment access.
Not recommended for vertical downward thrust applications exceeding 300kgf.
| Property | Property Value |
|---|---|
| sku | SAUJ100X1000-100 |
| Adjustable Stroke | 100mm |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT 1/2 |
| Magnet | Non-magnetic |
| Bore Diameter | 100mm |
| Stroke | <1000mm> |
