Airtac SAUJ100 Adjustable Cylinder SAUJ100X1000-100S
2. Features specially-shaped bidirectional piston sealing structure with integrated oil reservoir, ensuring compact dimensions;
3. Constructed with milled cross-shaped aluminum tubing (rodless design) offering superior corrosion resistance, integrated sensor mounting grooves for enhanced accessibility;
4. Compact length compared to ISO15552 standard cylinders of equivalent bore size within SAU series;
5. Precision-engineered adjustable cushioning mechanism for smooth operation;
6. Mounting accessories compatible with SC series cylinders;
7. High-temperature resistant seals (operating range: 0-150°C) for extreme environment applications.
Category: Standard Cylinders | Brand: AirTAC | Series: SAUJ100 Adjustable Cylinder
AirTAC SAUJ100 Adjustable Cylinder SAUJ100X1000-100S Technical Specifications
- Model: SAUJ100X1000-100S
- Type: Double-acting adjustable stroke cylinder
- Bore size: Ø100mm (ISO standard)
- Stroke length: 1000mm (maximum travel)
- Adjustment range: 50-1000mm (stepless position control)
- Operating pressure: 0.15–1.0 MPa
- Cushioning: Adjustable rubber bumper + air cushion
- Mounting style: MF1 front flange with integrated mounting holes
- Operating temperature: -20℃ to 80℃
- Port size: G3/8 (NPT1/2 optional)
- Seal material: Nitrile (NBR) with wear-resistant guide rings
- Weight: 23.5kg (unpressurized, without accessories)
- Dimensions: 1180mm(L) × 128mm(W) × 128mm(H)
- Position detection: Pre-installed magnet for sensor mounting
- Rod end: M30×1.5 external thread
Heavy-duty adjustable stroke cylinder engineered for precision long-stroke applications. Features dual-position locking mechanism with graduated scale for millimeter-level accuracy. The hardened chromium piston rod (HRC 45-50) and anti-rotation design ensure stable linear motion under high side loads. Includes built-in cushioning adjustment screws and dust-resistant wiper seal.
- Automated palletizing systems with variable stack heights
- Press machine stroke adjustment mechanisms
- Solar panel angle adjustment actuators
- Automotive assembly line positioning fixtures
- Plastic injection molding ejector systems
Installation note:
Always install with 0.1-0.3mm alignment clearance for thermal expansion.
Lubricate with ISO VG32 hydraulic oil before initial operation.
For full stroke adjustments, reduce operating pressure below 0.6 MPa.
| Property | Property Value |
|---|---|
| sku | SAUJ100X1000-100S |
| Adjustable Stroke | 100mm |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT 1/2 |
| Magnet | S-Magnetic |
| Bore Diameter | 100mm |
| Stroke | <1000mm> |
