Airtac SAUJ100 Adjustable Cylinder SAUJ100X1000-20S
2. Features specially-shaped bidirectional piston sealing structure with integrated oil reservoir, ensuring compact dimensions;
3. Constructed with milled cross-shaped aluminum tubing (rodless design) offering superior corrosion resistance, integrated sensor mounting grooves for enhanced accessibility;
4. Compact length compared to ISO15552 standard cylinders of equivalent bore size within SAU series;
5. Precision-engineered adjustable cushioning mechanism for smooth operation;
6. Mounting accessories compatible with SC series cylinders;
7. High-temperature resistant seals (operating range: 0-150°C) for extreme environment applications.
Category: Standard Cylinders | Brand: AirTAC | Series: SAUJ100 Adjustable Cylinder
AirTAC SAUJ100X1000-20S Adjustable Cylinder Specifications
- Model: SAUJ100X1000-20S
- Type: Double-acting adjustable stroke cylinder (ISO 15552 standard)
- Bore size: Ø100 mm
- Stroke: 1000 mm (adjustable through external stoppers)
- Operating pressure: 0.1–0.9 MPa
- Cushioning type: Adjustable pneumatic cushion at both ends
- Rod diameter: Ø25 mm (chrome-plated steel)
- Mounting style: Standard ISO flange (alternative options available)
- Port size: G3/8 (NPT1/2 optional)
- Temperature range: -20℃ to +80℃
- Seal material: Nitrile rubber (HNBR upgrade available)
- Weight: 28.5 kg (excluding mounting accessories)
- Dimensions: 1320mm(L) × 135mm(W) × 135mm(H) (full extension)
- Protection rating: IP54 (wipers included)
- Max piston speed: 0.5 m/s
- Lubrication: Pre-lubricated (use ISO VG32 pneumatic oil)
High-precision industrial cylinder with stroke adjustment mechanism, featuring dual external threaded stoppers (±2mm positioning accuracy) for fine-tuning without disassembly. The heavy-duty construction with aluminum alloy barrel and hardened piston rod ensures durability in continuous operation. Includes magnetic piston for position sensing compatibility.
- Automated production line material handling
- Press machine stroke control systems
- Automotive assembly positioning devices
- Packaging equipment with variable product sizes
- Plastic injection molding ejector mechanisms
Installation note:
Ensure proper alignment (max 0.2° angular misalignment) and use vibration-proof mounting brackets.
Allow 50mm clearance at adjustment ends for stopper operation. Lubricate guide shafts monthly in high-cycle applications.
| Property | Property Value |
|---|---|
| sku | SAUJ100X1000-20S |
| Adjustable Stroke | <20mm> |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT 1/2 |
| Magnet | S-Magnetic |
| Bore Diameter | 100mm |
| Stroke | <1000mm> |
