Airtac SAUJ100 Adjustable Cylinder SAUJ100X1000-30
2. Features specially-shaped bidirectional piston sealing structure with integrated oil reservoir, ensuring compact dimensions;
3. Constructed with milled cross-shaped aluminum tubing (rodless design) offering superior corrosion resistance, integrated sensor mounting grooves for enhanced accessibility;
4. Compact length compared to ISO15552 standard cylinders of equivalent bore size within SAU series;
5. Precision-engineered adjustable cushioning mechanism for smooth operation;
6. Mounting accessories compatible with SC series cylinders;
7. High-temperature resistant seals (operating range: 0-150°C) for extreme environment applications.
Category: Standard Cylinders | Brand: AirTAC | Series: SAUJ100 Adjustable Cylinder
AirTAC SAUJ100 Adjustable Cylinder SAUJ100X1000-30 Technical Specifications
- Full model: SAUJ100X1000-30
- Bore size: Ø100mm
- Stroke: 1000mm (adjustable)
- Operating pressure: 0.1-0.9 MPa
- Cushioning type: Adjustable pneumatic cushion (both ends)
- Piston speed: 50-800 mm/s
- Ambient temperature: -20℃ to 80℃
- Mounting style: Front flange/Foot mounting (MF1)
- Rod end thread: M30×2 (external)
- Stroke adjustment range: ±5mm (via external stopper)
- Repeat positioning accuracy: ±0.5mm
- Material: Aluminum alloy barrel, hardened steel piston rod
- Seal material: NBR with wear-resistant ring
- Weight: 18.7kg (without accessories)
- Dimensions: 1150mm(L) × 135mm(W) × 135mm(H)
- ISO standard: 15552 compliant
- Lubrication: Pre-lubricated (Oil-free operation possible)
High-precision long-stroke cylinder featuring dual adjustable air cushions for smooth deceleration. The hardened chrome-plated rod with multi-lip seals ensures dust resistance in harsh environments. Integrated mounting slots allow flexible installation configurations. Optional magnetic piston version available (add "-M" suffix).
- Automated pallet stacking systems
- Press machine ejection mechanisms
- Automotive assembly line positioning
- Large-format CNC machine tool clamping
- Packaging line product transfer gates
Installation note:
Maintain 0.5-1mm alignment tolerance during mounting. For vertical installations exceeding 45° angle,
use rod-end support brackets. Lubricate guide rods every 500km of cumulative travel.
- Air filter replacement: Every 3,000 operating hours
- Cushion needle adjustment: Every 500,000 cycles
- Full seal replacement: 5,000km travel or 3 years
| Property | Property Value |
|---|---|
| sku | SAUJ100X1000-30 |
| Adjustable Stroke | 30mm |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT 1/2 |
| Magnet | Non-magnetic |
| Bore Diameter | 100mm |
| Stroke | <1000mm> |
