Airtac SAUJ100 Adjustable Cylinder SAUJ100X1000-40
$398.70
Regular price
$406.20
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
SAUJ100X1000-40
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
1. Compliant with enterprise-standard cylinder specifications;
2. Features specially-shaped bidirectional piston sealing structure with integrated oil reservoir, ensuring compact dimensions;
3. Constructed with milled cross-shaped aluminum tubing (rodless design) offering superior corrosion resistance, integrated sensor mounting grooves for enhanced accessibility;
4. Compact length compared to ISO15552 standard cylinders of equivalent bore size within SAU series;
5. Precision-engineered adjustable cushioning mechanism for smooth operation;
6. Mounting accessories compatible with SC series cylinders;
7. High-temperature resistant seals (operating range: 0-150°C) for extreme environment applications.
Category: Standard Cylinders | Brand: AirTAC | Series: SAUJ100 Adjustable Cylinder
Installation tip:
For maximum stability in full extension, maintain horizontal mounting orientation.
Use locknuts on adjustment screws after calibration. Lubricate every 500km of travel.
2. Features specially-shaped bidirectional piston sealing structure with integrated oil reservoir, ensuring compact dimensions;
3. Constructed with milled cross-shaped aluminum tubing (rodless design) offering superior corrosion resistance, integrated sensor mounting grooves for enhanced accessibility;
4. Compact length compared to ISO15552 standard cylinders of equivalent bore size within SAU series;
5. Precision-engineered adjustable cushioning mechanism for smooth operation;
6. Mounting accessories compatible with SC series cylinders;
7. High-temperature resistant seals (operating range: 0-150°C) for extreme environment applications.
Category: Standard Cylinders | Brand: AirTAC | Series: SAUJ100 Adjustable Cylinder
AirTAC SAUJ100 Adjustable Cylinder SAUJ100X1000-40 Technical Details
- Full model code: SAUJ100X1000-40
- Type: Double-acting adjustable stroke cylinder
- Bore size: Ø40mm
- Stroke range: 50-1000mm (this model set to 1000mm)
- Operating pressure: 0.05-1.0 MPa
- Piston speed: 50-1000 mm/s
- Cushioning type: Adjustable elastic cushion (both ends)
- Mounting style: Basic type (optional flange/mounting brackets)
- Rod end thread: M16×1.5
- Ambient temperature: -10℃ to 80℃
- Seal material: Polyurethane (NBR optional)
- Weight: 3.8 kg ±2% (without accessories)
- Dimensions: 1215mm(L) × 50mm(W) × 50mm(H)
- Rod diameter: Ø16mm
- Maximum lateral load: 18N
- Air port size: G1/8
High-precision adjustable stroke cylinder with micrometer-style stroke adjustment mechanism (±0.5mm accuracy). Features double chrome-plated piston rod and aluminum alloy end caps. Integrated magnetic sensor slot (sensor not included). Requires 40μm filtered lubricated air (ISO 8573-1).
Common Applications:
- Variable position clamping in CNC fixtures
- Material handling systems requiring stroke adjustments
- Packaging machine ejection mechanisms
- Automated assembly line positioning
- Textile machinery tension control
Installation tip:
For maximum stability in full extension, maintain horizontal mounting orientation.
Use locknuts on adjustment screws after calibration. Lubricate every 500km of travel.
Stroke Adjustment:
- Loosen both end locknuts (17mm wrench size)
- Rotate adjustment collars (1 full rotation = 2mm stroke change)
- Check position with integrated scale markings
- Re-tighten locknuts to 3.5N·m torque
| Property | Property Value |
|---|---|
| sku | SAUJ100X1000-40 |
| Adjustable Stroke | <40mm> |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT 1/2 |
| Magnet | Non-magnetic |
| Bore Diameter | 100mm |
| Stroke | <1000mm> |
