Airtac SAUJ100 Adjustable Cylinder SAUJ100X1000-40S
2. Features specially-shaped bidirectional piston sealing structure with integrated oil reservoir, ensuring compact dimensions;
3. Constructed with milled cross-shaped aluminum tubing (rodless design) offering superior corrosion resistance, integrated sensor mounting grooves for enhanced accessibility;
4. Compact length compared to ISO15552 standard cylinders of equivalent bore size within SAU series;
5. Precision-engineered adjustable cushioning mechanism for smooth operation;
6. Mounting accessories compatible with SC series cylinders;
7. High-temperature resistant seals (operating range: 0-150°C) for extreme environment applications.
Category: Standard Cylinders | Brand: AirTAC | Series: SAUJ100 Adjustable Cylinder
AirTAC SAUJ100X1000-40S Adjustable Stroke Cylinder Specifications
- Model: SAUJ100X1000-40S
- Type: Double-acting adjustable stroke cylinder
- Bore size: 100mm
- Stroke: 1000mm (adjustable via external stopper)
- Operating pressure: 0.05–0.8 MPa
- Mounting style: Basic type (MF1) with front flange
- Cushioning: Adjustable pneumatic cushion (both ends)
- Port size: G1/2
- Piston rod material: Chrome-plated carbon steel (S45C)
- Tube material: Aluminum alloy (hard anodized)
- Seal material: NBR (nitrile rubber)
- Ambient temperature: -20℃ to 80℃
- Weight: 14.8kg (excluding accessories)
- Dimensions: 1215mm(L) × 132mm(W) × 132mm(H)
- Rod end type: Female thread M20×1.5
- Protection class: IP54 (standard wiper)
High-precision industrial cylinder with stroke adjustment mechanism, featuring dual-position locking screws for precise stroke control (±1mm repeatability). The hardened piston rod and multi-layered sealing system ensure reliable performance in high-cycle applications. Includes magnetic piston for position sensing compatibility.
- Palletizing robot arm extension control
- Press machine stroke adjustment systems
- Automotive welding fixture positioning
- Large-format CNC material handling
- Packaging line product ejection mechanisms
Installation note:
Ensure proper alignment of guide rods during assembly. Lubricate with ISO VG32 hydraulic oil
before initial operation. Maximum side load capacity: 350N at full extension.
| Property | Property Value |
|---|---|
| sku | SAUJ100X1000-40S |
| Adjustable Stroke | <40mm> |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT 1/2 |
| Magnet | S-Magnetic |
| Bore Diameter | 100mm |
| Stroke | <1000mm> |
