Airtac SAUJ100 Adjustable Cylinder SAUJ100X1000-50S
2. Features specially-shaped bidirectional piston sealing structure with integrated oil reservoir, ensuring compact dimensions;
3. Constructed with milled cross-shaped aluminum tubing (rodless design) offering superior corrosion resistance, integrated sensor mounting grooves for enhanced accessibility;
4. Compact length compared to ISO15552 standard cylinders of equivalent bore size within SAU series;
5. Precision-engineered adjustable cushioning mechanism for smooth operation;
6. Mounting accessories compatible with SC series cylinders;
7. High-temperature resistant seals (operating range: 0-150°C) for extreme environment applications.
Category: Standard Cylinders | Brand: AirTAC | Series: SAUJ100 Adjustable Cylinder
AirTAC SAUJ100 Adjustable Cylinder SAUJ100X1000-50S Technical Details
- Model Code: SAUJ100X1000-50S
- Type: Double-acting adjustable stroke cylinder
- Bore size: Ø100mm
- Stroke: 1000mm (adjustable)
- Operating pressure: 0.05-1.0 MPa
- Cushioning: Adjustable pneumatic cushion (both ends)
- Mounting style: Standard MF1 (front flange) with mounting holes
- Rod end: External thread M45x1.5
- Ambient temperature: -20℃ to 80℃
- Piston material: Aluminum alloy with hard anodizing
- Rod material: Stainless steel (SUS304)
- Seal type: NBR wear-resistant seals
- Port size: G1/2 (Rc1/2)
- Weight: 14.8kg ±2% (excluding accessories)
- Dimensions: 1250mm(L) x 140mm(W) x 140mm(H) (max extended length)
- Repeat positioning accuracy: ±0.5mm
- ISO standard: 15552 compliant
High-precision industrial cylinder with exceptional stroke adjustment capability through its unique mechanical locking mechanism. Features corrosion-resistant construction with IP54 protection rating, designed for heavy-load applications requiring precise linear motion control. The dual adjustable cushions minimize impact noise while allowing 10% stroke reduction capability through external adjustment screws.
- Automated palletizing systems
- Press machine ejection mechanisms
- Large-format CNC positioning tables
- Automotive assembly line fixtures
- Plastic injection molding machine components
Installation note:
Requires rigid mounting surface with flatness ≤0.1mm/m. Lubricate rod weekly with ISO VG32 hydraulic oil.
Maximum side load capacity: 350N at full extension. Allow 50mm clearance behind cylinder for stroke adjustment.
| Property | Property Value |
|---|---|
| sku | SAUJ100X1000-50S |
| Adjustable Stroke | <50mm> |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT 1/2 |
| Magnet | S-Magnetic |
| Bore Diameter | 100mm |
| Stroke | <1000mm> |
