Airtac SAUJ100 Adjustable Cylinder SAUJ100X1000-75
2. Features specially-shaped bidirectional piston sealing structure with integrated oil reservoir, ensuring compact dimensions;
3. Constructed with milled cross-shaped aluminum tubing (rodless design) offering superior corrosion resistance, integrated sensor mounting grooves for enhanced accessibility;
4. Compact length compared to ISO15552 standard cylinders of equivalent bore size within SAU series;
5. Precision-engineered adjustable cushioning mechanism for smooth operation;
6. Mounting accessories compatible with SC series cylinders;
7. High-temperature resistant seals (operating range: 0-150°C) for extreme environment applications.
Category: Standard Cylinders | Brand: AirTAC | Series: SAUJ100 Adjustable Cylinder
AirTAC SAUJ100 Adjustable Cylinder SAUJ100X1000-75 Technical Details
- Model Code: SAUJ100X1000-75
- Type: Double-acting adjustable stroke cylinder
- Bore Size: Ø100mm
- Stroke: 1000mm (adjustable via mechanical stopper)
- Operating Pressure: 0.05-1.0 MPa
- Cushioning: Adjustable pneumatic cushion at both ends
- Mounting Style: Basic type (no built-in mounting)
- Port Size: G3/8 (NPT1/4 optional)
- Operating Temperature: -20℃ to 80℃
- Piston Rod Material: Hard chrome-plated carbon steel
- Tube Material: Anodized aluminum alloy
- Seal Type: NBR + PU combination seals
- Weight: 12.8kg ±3%
- Dimensions (L×W×H):
- Extended: 1420mm × 118mm × 118mm
- Retracted: 420mm × 118mm × 118mm
- Adjustment Mechanism: External hex wrench adjustment with locknut
- Rod End Type: Female thread M20×1.5
- IP Rating: IP54 (standard wiper seal)
Heavy-duty adjustable stroke cylinder designed for precision positioning in long-stroke applications. Features dual shock absorption with 360° adjustable cushion screws and wear-resistant rod guides. The anodized barrel provides enhanced corrosion resistance for humid environments. Requires regular lubrication (ISO VG32 hydraulic oil recommended).
- Palletizing robot end-of-arm tooling
- Automotive assembly line clamping fixtures
- Sheet metal bending machine backgauges
- Warehouse vertical lift module positioning
- Plastic injection molding ejector systems
Installation tip:
Maintain 0.5mm minimum alignment tolerance during mounting. For vertical installations exceeding 45° angle,
add auxiliary rod support brackets every 800mm stroke length.
| Property | Property Value |
|---|---|
| sku | SAUJ100X1000-75 |
| Adjustable Stroke | 75mm |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT 1/2 |
| Magnet | Non-magnetic |
| Bore Diameter | 100mm |
| Stroke | <1000mm> |
