Airtac SAUJ32 Adjustable Stroke Cylinder SAUJ32X110-30
2. Features innovative bidirectional asymmetrical piston sealing structure with compact dimensions and integrated oil reservoir functionality;
3. Aluminum alloy tube with reinforced cross-rib design (eliminating tie rods), excellent corrosion resistance. External end incorporates sensor mounting grooves for convenient installation;
4. Compared to ISO 15662 standard cylinders, SAU series demonstrates reduced cylinder bore dimensions* and compact stroke length;
5. Precision-adjustable cushioning mechanism ensures smooth stroke termination;
6. Mounting accessories compatible with SC series cylinders for system integration flexibility;
7. High-temperature resistant sealing materials enable operational temperature range of 0-150°C.
Category: Standard Cylinders | Brand: AirTAC | Series: SAUJ32
AirTAC SAUJ32X110-30 Adjustable Stroke Cylinder Specifications
- Model: SAUJ32X110-30
- Type: Double-acting adjustable stroke cylinder
- Bore size: 32mm
- Stroke: 110mm (adjustable via external stop screws)
- Operating pressure: 0.15–1.0 MPa
- Cushioning type: External adjustable rubber bumper
- Mounting style: Basic type (MF1) with front thread M10×1.25
- Port size: G1/8 (ISO228 standard)
- Temperature range: -10℃ to 80℃
- Body material: Aluminum alloy (cylinder tube), CR12MoV piston rod
- Weight: 1.85kg ±2%
- Dimensions: 200mm(L) × 32mm(Bore) × 50mm(Mounting height)
- Rod end thread: M10×1.25 internal thread
- Piston seal: NBR with wear-resistant ring
- Max speed: 500mm/s
- Protection class: IP54 (standard wiper design)
Precision-adjustable pneumatic cylinder featuring micrometer-style stroke adjustment (±3mm fine-tuning capability). The dual locking nuts on adjustment screws ensure vibration-resistant positioning, with corrosion-resistant hard chrome plating on the piston rod (5-8μm thickness). Includes built-in magnetic sensor slot for position feedback compatibility.
- Precision workpiece clamping in CNC tool changers
- Variable height positioning in packaging line diverters
- Adjustable press mechanisms in electronic component assembly
- Material handling systems requiring stroke modification
- Automated paint sprayers with adjustable nozzle positions
Installation note:
Lubricate piston rod with ISO VG32 hydraulic oil before operation.
For vertical mounting, reduce max load capacity by 30%.
Adjustment screws require 0.5Nm torque limit during calibration.
| Property | Property Value |
|---|---|
| sku | SAUJ32X110-30 |
| Adjustable Stroke | 30mm |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT1/8 |
| Magnet | Non-magnetic |
| Bore Diameter | <32 mm> |
| Stroke | 110mm |
