Airtac SAUJ32 Adjustable Stroke Cylinder SAUJ32X110-30S
2. Features innovative bidirectional asymmetrical piston sealing structure with compact dimensions and integrated oil reservoir functionality;
3. Aluminum alloy tube with reinforced cross-rib design (eliminating tie rods), excellent corrosion resistance. External end incorporates sensor mounting grooves for convenient installation;
4. Compared to ISO 15662 standard cylinders, SAU series demonstrates reduced cylinder bore dimensions* and compact stroke length;
5. Precision-adjustable cushioning mechanism ensures smooth stroke termination;
6. Mounting accessories compatible with SC series cylinders for system integration flexibility;
7. High-temperature resistant sealing materials enable operational temperature range of 0-150°C.
Category: Standard Cylinders | Brand: AirTAC | Series: SAUJ32
AirTAC SAUJ32X110-30S Adjustable Cylinder Specifications
- Model: SAUJ32X110-30S
- Type: Double-acting adjustable stroke cylinder
- Bore size: 32mm (ISO 6432 standard)
- Stroke: 110mm (manually adjustable)
- Operating pressure: 0.05–1.0 MPa
- Cushioning: Adjustable pneumatic cushion (both ends)
- Port size: G1/8 (Rc1/8 optional)
- Mounting type: Basic (no built-in mounts)
- Temperature range: -10℃ to 80℃
- Piston rod material: Chrome-plated carbon steel
- Tube material: Anodized aluminum alloy
- Seal material: NBR (nitrile rubber)
- Weight: 1.45kg ±2%
- Dimensions:
- Extended length: 261mm
- Retracted length: 151mm
- Body diameter: 42mm
- Rod end thread: M12×1.25
Precision-adjustable pneumatic cylinder featuring dual-sided stroke adjustment screws (±3mm fine-tuning range) with locknuts. The 30S variant includes a magnetic piston for position sensing compatibility. Optimized for mid-stroke force applications with 3-stage wear compensation seals. Requires 5-40μm filtered air with ISO 8573-1:2010 class 4 purity.
- Variable height positioning in automated assembly lines
- Clamping force adjustment in CNC fixture systems
- Packaging machine stroke customization
- Textile machinery tension control
- Semiconductor handling equipment
Installation note:
Allow 15mm clearance around adjustment screws for maintenance access.
Lubricate with ISO VG32 pneumatic oil if used in dry air systems.
Max lateral load: 35N at full extension.
| Property | Property Value |
|---|---|
| sku | SAUJ32X110-30S |
| Adjustable Stroke | 30mm |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT1/8 |
| Magnet | S-Magnetic |
| Bore Diameter | <32 mm> |
| Stroke | 110mm |
