Airtac SAUJ32 Adjustable Stroke Cylinder SAUJ32X110-40
2. Features innovative bidirectional asymmetrical piston sealing structure with compact dimensions and integrated oil reservoir functionality;
3. Aluminum alloy tube with reinforced cross-rib design (eliminating tie rods), excellent corrosion resistance. External end incorporates sensor mounting grooves for convenient installation;
4. Compared to ISO 15662 standard cylinders, SAU series demonstrates reduced cylinder bore dimensions* and compact stroke length;
5. Precision-adjustable cushioning mechanism ensures smooth stroke termination;
6. Mounting accessories compatible with SC series cylinders for system integration flexibility;
7. High-temperature resistant sealing materials enable operational temperature range of 0-150°C.
Category: Standard Cylinders | Brand: AirTAC | Series: SAUJ32
AirTAC SAUJ32 Adjustable Stroke Cylinder SAUJ32X110-40 Technical Details
- Model: SAUJ32X110-40
- Bore size: 32mm
- Stroke: 110mm (adjustable)
- Operation type: Double-acting
- Working pressure: 0.05-1.0 MPa
- Medium temperature: -20℃ to 80℃
- Piston speed: 50-1000mm/s
- Cushioning: Adjustable air cushion
- Mounting type: Basic type (MF1) with front thread
- Rod end: External thread M14×1.5
- Port size: G1/8 (NPT1/8 optional)
- Seal material: NBR (Nitrile rubber)
- Body material: Aluminum alloy with hard anodizing
- Weight: 1.45kg ±2%
- Dimensions:
- Length (retracted): 219mm
- Width (body): 42mm
- Height (with rod): 64mm
Precision adjustable stroke cylinder featuring micrometer-style stroke adjustment mechanism (±2mm fine-tuning). The dual piston design ensures smooth operation with minimal stick-slip effect. Includes built-in magnetic sensor slot (M9 connector compatible) for position feedback. Rated for 5,000km service life under standard conditions.
- CNC machine tool clamping mechanisms
- Automated assembly line positioning stops
- Plastic injection molding ejectors
- Semiconductor wafer handling systems
- Packaging machine product pushers
Maintenance tip:
Lubricate with ISO VG32 hydraulic oil through air line lubricator.
Avoid side load exceeding 30N. For vertical mounting,
use model with lock nut (add "-L" suffix).
| Property | Property Value |
|---|---|
| sku | SAUJ32X110-40 |
| Adjustable Stroke | <40mm> |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT1/8 |
| Magnet | Non-magnetic |
| Bore Diameter | <32 mm> |
| Stroke | 110mm |
