Airtac SAUJ32 Adjustable Stroke Cylinder SAUJ32X110-50S
2. Features innovative bidirectional asymmetrical piston sealing structure with compact dimensions and integrated oil reservoir functionality;
3. Aluminum alloy tube with reinforced cross-rib design (eliminating tie rods), excellent corrosion resistance. External end incorporates sensor mounting grooves for convenient installation;
4. Compared to ISO 15662 standard cylinders, SAU series demonstrates reduced cylinder bore dimensions* and compact stroke length;
5. Precision-adjustable cushioning mechanism ensures smooth stroke termination;
6. Mounting accessories compatible with SC series cylinders for system integration flexibility;
7. High-temperature resistant sealing materials enable operational temperature range of 0-150°C.
Category: Standard Cylinders | Brand: AirTAC | Series: SAUJ32
AirTAC SAUJ32 Adjustable Cylinder SAUJ32X110-50S Technical Details
- Model: SAUJ32X110-50S
- Type: Double-acting adjustable stroke cylinder
- Bore size: 32mm
- Stroke: 110mm (adjustable range: 50-110mm)
- Stroke adjustment mechanism: External mechanical stopper
- Operating pressure: 0.05-1.0 MPa
- Temperature range: -10℃ to 80℃
- Port size: 1/4" NPT (G1/8 optional)
- Cushioning: Air cushion with adjustable buffer
- Mounting style: Basic type (MF1)
- Rod material: Hard chrome-plated steel
- Tube material: Aluminum alloy anodized
- Seal material: NBR/PU
- Weight: 1.65kg ±3%
- Dimensions:
- Extended length: 271mm
- Retracted length: 161mm
- Body diameter: 40mm
- Mounting bracket width: 54mm
Precision-adjustable pneumatic cylinder featuring dual-position stroke control through external mechanical stops. The 3-stage anodized barrel provides enhanced corrosion resistance, while the triple-lip rod seal ensures minimal leakage. Includes magnetic piston for position sensing compatibility (sensor not included). Requires ISO 8573-1:2010 [3:4:3] class compressed air.
- Variable stroke press machines
- Automated material handling systems
- Plastic injection molding ejectors
- Precision clamping fixtures
- Semiconductor wafer handling
Operation tip:
Lubricate with ISO VG32 pneumatic oil monthly. For fine adjustments,
loosen the locknut and rotate stopper screw (2mm pitch = 1mm stroke change).
Maximum side load: 15N at full extension.
| Property | Property Value |
|---|---|
| sku | SAUJ32X110-50S |
| Adjustable Stroke | <50mm> |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT1/8 |
| Magnet | S-Magnetic |
| Bore Diameter | <32 mm> |
| Stroke | 110mm |
