Airtac SAUJ32 Adjustable Stroke Cylinder SAUJ32X110-75
2. Features innovative bidirectional asymmetrical piston sealing structure with compact dimensions and integrated oil reservoir functionality;
3. Aluminum alloy tube with reinforced cross-rib design (eliminating tie rods), excellent corrosion resistance. External end incorporates sensor mounting grooves for convenient installation;
4. Compared to ISO 15662 standard cylinders, SAU series demonstrates reduced cylinder bore dimensions* and compact stroke length;
5. Precision-adjustable cushioning mechanism ensures smooth stroke termination;
6. Mounting accessories compatible with SC series cylinders for system integration flexibility;
7. High-temperature resistant sealing materials enable operational temperature range of 0-150°C.
Category: Standard Cylinders | Brand: AirTAC | Series: SAUJ32
AirTAC SAUJ32X110-75 Adjustable Stroke Cylinder Technical Details
- Model: SAUJ32X110-75
- Type: Double-acting adjustable stroke cylinder
- Bore size: 32mm (ISO 6432 standard)
- Stroke: 110mm (adjustable range ±5mm)
- Stroke adjustment: Manual screw-type with locking nut
- Operating pressure: 0.1–0.9 MPa
- Temperature range: -20℃ to 80℃
- Port size: PT1/8 (G1/8 optional)
- Cushioning: Adjustable pneumatic cushion (both ends)
- Mounting: Front/rear threaded (M12×1.25) or foot-mounted
- Material: Aluminum alloy barrel, CR-SEALS® NBR seals
- Weight: 1.45kg (bare cylinder)
- Dimensions: 200mm(L) × 52mm(W) × 52mm(H) (fully retracted)
- Extended length: 310mm (max stroke position)
- Rod thread: M10×1.25 external thread
- Piston speed: 50–700mm/s (lubricated operation)
Precision-adjustable pneumatic cylinder featuring dual-position mechanical stops for micro-stroke calibration (±5mm). Incorporates corrosion-resistant hard anodized piston rod and wear-resistant guide bands. Includes integrated shock absorbers with 3-stage damping adjustment via hex key. Suitable for vertical/horizontal mounting with optional magnetic piston for position sensing.
- Precision part insertion in robotic assembly lines
- Variable height positioning in semiconductor handling
- Pressure-sensitive clamping systems (mold/die casting)
- Textile machinery with space-constrained stroke adjustment
- Automated packaging equipment requiring force control
Installation guidance:
For optimal performance, maintain 0.5–1mm clearance between stopper screws during adjustment.
Lubricate with ISO VG32 turbine oil (non-detergent) every 500km of cumulative travel.
Critical note:
Avoid side-load exceeding 30N during operation. When used in vertical downward orientation,
install speed controller on rod end port to prevent piston slam.
| Property | Property Value |
|---|---|
| sku | SAUJ32X110-75 |
| Adjustable Stroke | 75mm |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT1/8 |
| Magnet | Non-magnetic |
| Bore Diameter | <32 mm> |
| Stroke | 110mm |
