Airtac SAUJ32 Adjustable Stroke Cylinder SAUJ32X110-75S
2. Features innovative bidirectional asymmetrical piston sealing structure with compact dimensions and integrated oil reservoir functionality;
3. Aluminum alloy tube with reinforced cross-rib design (eliminating tie rods), excellent corrosion resistance. External end incorporates sensor mounting grooves for convenient installation;
4. Compared to ISO 15662 standard cylinders, SAU series demonstrates reduced cylinder bore dimensions* and compact stroke length;
5. Precision-adjustable cushioning mechanism ensures smooth stroke termination;
6. Mounting accessories compatible with SC series cylinders for system integration flexibility;
7. High-temperature resistant sealing materials enable operational temperature range of 0-150°C.
Category: Standard Cylinders | Brand: AirTAC | Series: SAUJ32
AirTAC SAUJ32X110-75S Adjustable Cylinder Specifications
- Model: SAUJ32X110-75S
- Type: Double-acting adjustable stroke cylinder
- Bore size: 32mm
- Stroke: 110mm (adjustable)
- Adjustment range: ±2mm via mechanical stopper
- Operating pressure: 0.05–1.0 MPa
- Max thrust: 245N at 0.63MPa
- Port size: Rc1/8 (G1/8 optional)
- Cushioning: Rubber buffer + adjustable screw
- Piston rod material: Chrome-plated carbon steel (S45C)
- Tube material: Anodized aluminum alloy
- Seal material: NBR + PU hybrid
- Temperature range: -10℃ to 80℃
- Weight: 1.65kg ±3%
- Dimensions: 212mm(L) × 50mm(W) × 50mm(H) (retracted)
- Mounting: Standard ISO 15552 foot & front flange
- Protection rating: IP54 (standard seals)
Precision-adjustable pneumatic cylinder featuring dual-position mechanical stoppers for micro-positioning. The 75S variant includes a reinforced rod end with anti-rotation slot (6mm width) and wear-resistant guide rings. Optimized for applications requiring repetitive position accuracy within ±0.2mm tolerance.
- CNC machine tool clamping mechanisms
- Glass panel press-fit positioning systems
- Pharmaceutical blister packaging machines
- Automotive welding fixture alignment
- PCB board assembly presses
Installation note:
Lubricate adjustment screws with Molykote EM-30L grease before initial use.
Max lateral load: 15N at rod end. For vertical mounting, use counterbalance valve.
| Property | Property Value |
|---|---|
| sku | SAUJ32X110-75S |
| Adjustable Stroke | 75mm |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT1/8 |
| Magnet | S-Magnetic |
| Bore Diameter | <32 mm> |
| Stroke | 110mm |
