Airtac SAUJ32 Adjustable Stroke Cylinder SAUJ32X115-100
$60.91
Regular price
$68.41
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
SAUJ32X115-100
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
1. Compliant with enterprise-standard cylinder specifications;
2. Features innovative bidirectional asymmetrical piston sealing structure with compact dimensions and integrated oil reservoir functionality;
3. Aluminum alloy tube with reinforced cross-rib design (eliminating tie rods), excellent corrosion resistance. External end incorporates sensor mounting grooves for convenient installation;
4. Compared to ISO 15662 standard cylinders, SAU series demonstrates reduced cylinder bore dimensions* and compact stroke length;
5. Precision-adjustable cushioning mechanism ensures smooth stroke termination;
6. Mounting accessories compatible with SC series cylinders for system integration flexibility;
7. High-temperature resistant sealing materials enable operational temperature range of 0-150°C.
Category: Standard Cylinders | Brand: AirTAC | Series: SAUJ32
Installation guidelines:
Use M6x1.0 mounting screws with 12.9 grade hardness. Maintain 0.05mm maximum
misalignment during installation. Lubricate with ISO VG32 hydraulic oil
during initial setup. For vertical mounting, install air exhaust silencers
above 0.7MPa pressure.
2. Features innovative bidirectional asymmetrical piston sealing structure with compact dimensions and integrated oil reservoir functionality;
3. Aluminum alloy tube with reinforced cross-rib design (eliminating tie rods), excellent corrosion resistance. External end incorporates sensor mounting grooves for convenient installation;
4. Compared to ISO 15662 standard cylinders, SAU series demonstrates reduced cylinder bore dimensions* and compact stroke length;
5. Precision-adjustable cushioning mechanism ensures smooth stroke termination;
6. Mounting accessories compatible with SC series cylinders for system integration flexibility;
7. High-temperature resistant sealing materials enable operational temperature range of 0-150°C.
Category: Standard Cylinders | Brand: AirTAC | Series: SAUJ32
AirTAC SAUJ32X115-100 Adjustable Stroke Cylinder Specifications
- Model: SAUJ32X115-100
- Type: Double-acting adjustable stroke cylinder
- Bore size: Ø32mm
- Stroke range: 50-115mm (adjustable)
- Max stroke: 115mm
- Rod diameter: Ø12mm
- Operating pressure: 0.15-1.0 MPa
- Cushion type: Air cushion adjustable (both ends)
- Port size: G1/8 (NPT1/8 optional)
- Operating temperature: -20℃ to 80℃
- Seal material: NBR/PU (oil & heat resistant)
- Body material: Aluminum alloy (anodized)
- Weight: 1.65kg ±2%
- Dimensions:
- Extended length: 273mm
- Retracted length: 158mm
- Width (mounting bracket): 42mm
- Height (body diameter): Ø40mm
- ISO standard: 6432 (mounting compatibility)
Precision-adjustable pneumatic cylinder featuring micrometer-style stroke adjustment with ±0.5mm repeatability. The dual locking mechanism maintains position stability under 0.5MPa residual pressure. Integrated shock absorbers reduce end-impact noise by 15dB compared to standard models.
Typical Applications:
- Variable height positioning in semiconductor handling
- Press-fit force adjustment in automotive assembly
- Packaging line product height compensation
- Textile machinery tension control systems
- 3C product testing equipment with stroke calibration
Installation guidelines:
Use M6x1.0 mounting screws with 12.9 grade hardness. Maintain 0.05mm maximum
misalignment during installation. Lubricate with ISO VG32 hydraulic oil
during initial setup. For vertical mounting, install air exhaust silencers
above 0.7MPa pressure.
Adjustment procedure:
- Loosen the lock nut (M16x1.5)
- Rotate adjustment dial (0-100 scale)
- 1 full rotation = 2mm stroke change
- Re-torque nut to 4.5±0.5 N·m
| Property | Property Value |
|---|---|
| sku | SAUJ32X115-100 |
| Adjustable Stroke | 100mm |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT1/8 |
| Magnet | Non-magnetic |
| Bore Diameter | <32 mm> |
| Stroke | 115mm |
