Airtac SAUJ32 Adjustable Stroke Cylinder SAUJ32X115-100S
2. Features innovative bidirectional asymmetrical piston sealing structure with compact dimensions and integrated oil reservoir functionality;
3. Aluminum alloy tube with reinforced cross-rib design (eliminating tie rods), excellent corrosion resistance. External end incorporates sensor mounting grooves for convenient installation;
4. Compared to ISO 15662 standard cylinders, SAU series demonstrates reduced cylinder bore dimensions* and compact stroke length;
5. Precision-adjustable cushioning mechanism ensures smooth stroke termination;
6. Mounting accessories compatible with SC series cylinders for system integration flexibility;
7. High-temperature resistant sealing materials enable operational temperature range of 0-150°C.
Category: Standard Cylinders | Brand: AirTAC | Series: SAUJ32
AirTAC SAUJ32 Adjustable Stroke Cylinder SAUJ32X115-100S Technical Details
- Model Code: SAUJ32X115-100S
- Cylinder Type: Double-acting adjustable stroke
- Bore Size: 32mm
- Stroke Length: 115mm (adjustable range: 0-100mm)
- Operating Pressure: 0.1-0.9 MPa
- Cushioning: Adjustable pneumatic cushion at both ends
- Mounting Style: Front flange/Foot mounting (ISO 15552 standard)
- Port Size: G1/8 (NPT1/8 optional)
- Operating Temperature: -20℃ to 80℃
- Piston Material: Aluminum alloy with hard anodized surface
- Rod Material: Chrome-plated steel (Cr-Mo steel)
- Seal Material: NBR (Nitrile rubber)
- Weight: 1.65 kg (with standard accessories)
- Dimensions: 298mm(L) × 40mm(W) × 52mm(H) (minimum retracted length)
- Stroke Adjustment: Mechanical stopper with locknut
- Repeat Positioning Accuracy: ±0.5mm
- IP Rating: IP54 (standard wiper seal)
Precision-engineered adjustable stroke cylinder featuring a unique mechanical stopper system for fine-tuning stroke length without disassembly. The chrome-plated piston rod integrates wear-resistant technology, while the double cushioning mechanism enables smooth deceleration across 100% stroke adjustability. Includes built-in magnet for position sensing compatibility.
- Variable position clamping in CNC tool changers
- Adjustable press mechanisms for plastic molding
- Material handling systems requiring variable reach
- Automated packaging line positioning arms
- Semiconductor wafer handling equipment
Installation Tip:
For optimal performance, lubricate the adjustment screw threads with molybdenum disulfide grease
and perform stroke calibration at 0.4-0.6 MPa air pressure. Maintain 50mm clearance behind the
cylinder for full stroke adjustment access.
| Property | Property Value |
|---|---|
| sku | SAUJ32X115-100S |
| Adjustable Stroke | 100mm |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT1/8 |
| Magnet | S-Magnetic |
| Bore Diameter | <32 mm> |
| Stroke | 115mm |
