Airtac SAUJ32 Adjustable Stroke Cylinder SAUJ32X115-10S
$63.70
Regular price
$71.20
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
SAUJ32X115-10S
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
1. Compliant with enterprise-standard cylinder specifications;
2. Features innovative bidirectional asymmetrical piston sealing structure with compact dimensions and integrated oil reservoir functionality;
3. Aluminum alloy tube with reinforced cross-rib design (eliminating tie rods), excellent corrosion resistance. External end incorporates sensor mounting grooves for convenient installation;
4. Compared to ISO 15662 standard cylinders, SAU series demonstrates reduced cylinder bore dimensions* and compact stroke length;
5. Precision-adjustable cushioning mechanism ensures smooth stroke termination;
6. Mounting accessories compatible with SC series cylinders for system integration flexibility;
7. High-temperature resistant sealing materials enable operational temperature range of 0-150°C.
Category: Standard Cylinders | Brand: AirTAC | Series: SAUJ32
Installation note:
Adjust cushion screws incrementally (1/4 turns) while monitoring stroke performance.
Maintain 0.3-0.5mm clearance between rod end and load during alignment.
Use clean dry air with 5-40μm filtration to prevent seal degradation.
2. Features innovative bidirectional asymmetrical piston sealing structure with compact dimensions and integrated oil reservoir functionality;
3. Aluminum alloy tube with reinforced cross-rib design (eliminating tie rods), excellent corrosion resistance. External end incorporates sensor mounting grooves for convenient installation;
4. Compared to ISO 15662 standard cylinders, SAU series demonstrates reduced cylinder bore dimensions* and compact stroke length;
5. Precision-adjustable cushioning mechanism ensures smooth stroke termination;
6. Mounting accessories compatible with SC series cylinders for system integration flexibility;
7. High-temperature resistant sealing materials enable operational temperature range of 0-150°C.
Category: Standard Cylinders | Brand: AirTAC | Series: SAUJ32
AirTAC SAUJ32 Adjustable Cushioning Cylinder SAUJ32X115-10S Specifications
- Model: SAUJ32X115-10S
- Series: SAUJ (Square Type Adjustable Cushioning)
- Bore size: 32mm
- Stroke: 115mm
- Cushion type: Adjustable (both ends)
- Mounting style: Square type with fixed mounting holes
- Operating pressure: 0.15–0.8 MPa
- Operating temperature: -20℃ to 80℃
- Piston speed: 50–800 mm/s
- Seal material: NBR (Nitrile Butadiene Rubber)
- Rod material: Hard chrome-plated steel
- Tube material: Aluminum alloy (anodized)
- Protection rating: IP65
- Weight: 1.2kg ±5%
- Dimensions (L×W×H): 200mm × 40mm × 40mm (excluding rod extension)
- Port size: M5x0.8 (standard), G1/8 optional
- Max lateral load: 18N
- Lubrication: Pre-lubricated (grease-free operation)
Precision-engineered compact cylinder featuring dual adjustable pneumatic cushions for smooth end-of-stroke deceleration. The square body design enables direct mounting without additional brackets. Hardened piston rod with multi-lip seals ensures dust resistance and extended service life in harsh environments.
Typical Applications:
- Precision positioning in automated assembly lines
- Material handling equipment with space constraints
- Packaging machinery requiring controlled force application
- Electronics manufacturing pick-and-place systems
- Printing press component actuation
Installation note:
Adjust cushion screws incrementally (1/4 turns) while monitoring stroke performance.
Maintain 0.3-0.5mm clearance between rod end and load during alignment.
Use clean dry air with 5-40μm filtration to prevent seal degradation.
| Property | Property Value |
|---|---|
| sku | SAUJ32X115-10S |
| Adjustable Stroke | <10mm> |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT1/8 |
| Magnet | S-Magnetic |
| Bore Diameter | <32 mm> |
| Stroke | 115mm |
