Airtac SAUJ32 Adjustable Stroke Cylinder SAUJ32X115-20
$60.91
Regular price
$68.41
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
SAUJ32X115-20
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
1. Compliant with enterprise-standard cylinder specifications;
2. Features innovative bidirectional asymmetrical piston sealing structure with compact dimensions and integrated oil reservoir functionality;
3. Aluminum alloy tube with reinforced cross-rib design (eliminating tie rods), excellent corrosion resistance. External end incorporates sensor mounting grooves for convenient installation;
4. Compared to ISO 15662 standard cylinders, SAU series demonstrates reduced cylinder bore dimensions* and compact stroke length;
5. Precision-adjustable cushioning mechanism ensures smooth stroke termination;
6. Mounting accessories compatible with SC series cylinders for system integration flexibility;
7. High-temperature resistant sealing materials enable operational temperature range of 0-150°C.
Category: Standard Cylinders | Brand: AirTAC | Series: SAUJ32
Installation guidance:
Apply thread locker (medium strength) to adjustment nuts. Lubricate with ISO VG32 hydraulic oil
during initial installation. Allow 20mm clearance behind adjustment mechanism for tool access.
2. Features innovative bidirectional asymmetrical piston sealing structure with compact dimensions and integrated oil reservoir functionality;
3. Aluminum alloy tube with reinforced cross-rib design (eliminating tie rods), excellent corrosion resistance. External end incorporates sensor mounting grooves for convenient installation;
4. Compared to ISO 15662 standard cylinders, SAU series demonstrates reduced cylinder bore dimensions* and compact stroke length;
5. Precision-adjustable cushioning mechanism ensures smooth stroke termination;
6. Mounting accessories compatible with SC series cylinders for system integration flexibility;
7. High-temperature resistant sealing materials enable operational temperature range of 0-150°C.
Category: Standard Cylinders | Brand: AirTAC | Series: SAUJ32
AirTAC SAUJ32X115-20 Adjustable Stroke Cylinder Technical Details
- Series: SAUJ (Standard Adjustable Stroke)
- Bore size: 32mm
- Stroke length: 115mm (adjustable through mechanical stops)
- Rod diameter: 12mm
- Operating pressure: 0.05-0.9 MPa
- Cushioning type: Adjustable elastic cushion at both ends
- Port size: M5x0.8 (G1/8 adapter available)
- Mounting type: Basic (no built-in mounting, requires separate bracket)
- Piston speed: 50-750 mm/s
- Ambient temperature: -10℃ to 80℃
- Seal material: Polyurethane (NBR optional)
- Weight: 1.35kg ±2%
- Dimensions: 178mm(L) × 42mm(W) × 42mm(H) (excluding rod extension)
- Rod thread: M12x1.25 external thread
- Repeat positioning accuracy: ±0.5mm
Precision-adjustable pneumatic cylinder featuring dual mechanical stop collars for infinite stroke adjustment within 115mm range. The chrome-plated piston rod with integrated locknuts enables precise end-position calibration. Designed for applications requiring variable stroke settings without disassembly.
Industrial Applications:
- Variable height positioning in packaging machinery
- Adjustable clamping force applications
- Semiconductor handling equipment with Z-axis adjustment
- Automated welding jig positioning systems
- Printing press roller engagement control
Installation guidance:
Apply thread locker (medium strength) to adjustment nuts. Lubricate with ISO VG32 hydraulic oil
during initial installation. Allow 20mm clearance behind adjustment mechanism for tool access.
Cycle Life: 5,000km cumulative stroke distance (recommended rebuild interval) under standard operating conditions. Replace cushion seals every 1.2 million cycles in high-speed applications.
| Property | Property Value |
|---|---|
| sku | SAUJ32X115-20 |
| Adjustable Stroke | <20mm> |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT1/8 |
| Magnet | Non-magnetic |
| Bore Diameter | <32 mm> |
| Stroke | 115mm |
