Airtac SAUJ32 Adjustable Stroke Cylinder SAUJ32X115-30
2. Features innovative bidirectional asymmetrical piston sealing structure with compact dimensions and integrated oil reservoir functionality;
3. Aluminum alloy tube with reinforced cross-rib design (eliminating tie rods), excellent corrosion resistance. External end incorporates sensor mounting grooves for convenient installation;
4. Compared to ISO 15662 standard cylinders, SAU series demonstrates reduced cylinder bore dimensions* and compact stroke length;
5. Precision-adjustable cushioning mechanism ensures smooth stroke termination;
6. Mounting accessories compatible with SC series cylinders for system integration flexibility;
7. High-temperature resistant sealing materials enable operational temperature range of 0-150°C.
Category: Standard Cylinders | Brand: AirTAC | Series: SAUJ32
AirTAC SAUJ32X115-30 Adjustable Cylinder Specifications
- Model: SAUJ32X115-30
- Type: Double-acting adjustable stroke cylinder
- Bore size: 32mm
- Stroke: 115mm (adjustable)
- Operating pressure: 0.05–1.0 MPa
- Cushioning type: Adjustable buffer (both ends)
- Port thread: G1/8 (ISO228 standard)
- Piston speed: 50–800 mm/s
- Ambient temperature: -20℃ to 80℃
- Seal material: NBR + PU combination
- Rod material: Chrome-plated carbon steel
- Body material: Aluminum alloy (6063-T5)
- Mounting type: Basic (axial mounting holes)
- Weight: 1.65 kg ±2%
- Dimensions:
- Extended length: 273mm
- Retracted length: 158mm
- Body diameter: 32mm ±0.5mm
- Rod diameter: 12mm
- Mounting hole spacing: 25mm (M6x1.0 threads)
Precision-engineered adjustable stroke cylinder featuring dual-position mechanical stops for mid-stroke positioning. The enhanced buffer system reduces end-impact noise to ≤70dB(A). Integrated wear-resistant guide bush ensures 5000km+ service life under standard conditions. Compatible with ISO 6432 mounting accessories.
- CNC machine tool clamping mechanisms
- Automated production line positioning fixtures
- Packaging machine stroke adjustment systems
- Semiconductor handling equipment
- Automotive welding jig positioning
Operation note:
For optimal performance, lubricate with ISO VG32 hydraulic oil (1-2 drops per port)
during installation. Avoid lateral loads exceeding 30N. Maximum side load capacity
at mid-stroke: 15N·m torque resistance.
| Property | Property Value |
|---|---|
| sku | SAUJ32X115-30 |
| Adjustable Stroke | 30mm |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT1/8 |
| Magnet | Non-magnetic |
| Bore Diameter | <32 mm> |
| Stroke | 115mm |
