Airtac SAUJ32 Adjustable Stroke Cylinder SAUJ32X115-30S
2. Features innovative bidirectional asymmetrical piston sealing structure with compact dimensions and integrated oil reservoir functionality;
3. Aluminum alloy tube with reinforced cross-rib design (eliminating tie rods), excellent corrosion resistance. External end incorporates sensor mounting grooves for convenient installation;
4. Compared to ISO 15662 standard cylinders, SAU series demonstrates reduced cylinder bore dimensions* and compact stroke length;
5. Precision-adjustable cushioning mechanism ensures smooth stroke termination;
6. Mounting accessories compatible with SC series cylinders for system integration flexibility;
7. High-temperature resistant sealing materials enable operational temperature range of 0-150°C.
Category: Standard Cylinders | Brand: AirTAC | Series: SAUJ32
AirTAC SAUJ32 Adjustable Cylinder SAUJ32X115-30S Technical Details
- Model: SAUJ32X115-30S
- Type: Double-acting adjustable stroke cylinder
- Bore size: 32mm
- Stroke: 115mm (adjustable via mechanical stopper)
- Operating pressure: 0.15–0.8 MPa
- Cushioning: Adjustable pneumatic cushion (both ends)
- Stroke adjustment range: 0-100% of nominal stroke
- Mounting style: Front flange with through-hole (MF2)
- Port size: G1/8 (ISO standard)
- Operating temperature: -20℃ to 80℃
- Tube material: Aluminum alloy (hard anodized)
- Rod material: Chrome-plated carbon steel
- Seal material: NBR (nitrile rubber)
- Weight: 1.85kg ±2%
- Dimensions: 250mm(L) × 42mm(W) × 42mm(H)
- Rod thread: M12×1.25 (external)
- Protection rating: IP54 (standard wiper design)
Precision-engineered adjustable stroke cylinder featuring dual-sided stroke limiter with 360° rotatable adjustment mechanism. The through-rod design enables external position sensing compatibility. Optimized for applications requiring repeatable positioning accuracy (±0.5mm) without electronic feedback systems. Includes wear-resistant guide bushings and anti-rotation piston rod.
- Variable height positioning in automated assembly lines
- Material handling with adjustable clamping force
- Precision press mechanisms for electronic component manufacturing
- Packaging machine stopper adjustment systems
- Textile machinery thread tension control
Installation guidelines:
Lubricate with ISO VG32 hydraulic oil before initial use. Avoid side load exceeding 15N.
For optimal performance, maintain air filtration at 5μm or finer. Allow 0.5mm clearance
between stopper and cylinder during adjustment to prevent over-compression.
Critical note:
Maximum permissible lateral load: 30N at mid-stroke. When using full stroke reduction,
reduce working pressure by 20% to compensate for increased piston acceleration.
| Property | Property Value |
|---|---|
| sku | SAUJ32X115-30S |
| Adjustable Stroke | 30mm |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT1/8 |
| Magnet | S-Magnetic |
| Bore Diameter | <32 mm> |
| Stroke | 115mm |
