Airtac SAUJ32 Adjustable Stroke Cylinder SAUJ32X115-40
2. Features innovative bidirectional asymmetrical piston sealing structure with compact dimensions and integrated oil reservoir functionality;
3. Aluminum alloy tube with reinforced cross-rib design (eliminating tie rods), excellent corrosion resistance. External end incorporates sensor mounting grooves for convenient installation;
4. Compared to ISO 15662 standard cylinders, SAU series demonstrates reduced cylinder bore dimensions* and compact stroke length;
5. Precision-adjustable cushioning mechanism ensures smooth stroke termination;
6. Mounting accessories compatible with SC series cylinders for system integration flexibility;
7. High-temperature resistant sealing materials enable operational temperature range of 0-150°C.
Category: Standard Cylinders | Brand: AirTAC | Series: SAUJ32
AirTAC SAUJ32 Adjustable Stroke Cylinder SAUJ32X115-40 Technical Specifications
- Model Code: SAUJ32X115-40
- Type: Adjustable stroke double-acting cylinder
- Bore size: Ø32mm
- Stroke range: 40-115mm (mechanically adjustable)
- Operating pressure: 0.15-0.8 MPa
- Cushioning: Adjustable air cushion (both ends)
- Mounting style: Standard ISO 15552 foot & flange mounts
- Port size: M5x0.8 (G1/8 optional)
- Temperature range: -20℃ to 80℃
- Material:
- Tube: Aluminum alloy hard anodized
- Piston rod: Chrome-plated steel
- Seals: NBR (nitrile rubber)
- Weight: 1.45kg ±3%
- Dimensions:
- Extended length: 200mm (max stroke)
- Retracted length: 125mm (min stroke)
- Body diameter: Ø42mm
- Rod end thread: M10x1.25
Precision-adjustable pneumatic cylinder featuring patented stroke locking mechanism with ±0.5mm repeatability. The dual anti-rotation design maintains positional accuracy during repetitive movements. Integrated magnet slot allows for magnetic sensor installation (sensor sold separately). Maintenance-free operation up to 3,000km service life under standard conditions.
- Variable position clamping in CNC fixtures
- Packaging line product height adjustment systems
- Automated door stroke calibration
- Printing press roller engagement control
- Semiconductor handling equipment
Installation tip:
Always degrease rod threads before installing accessories.
For vertical mounting, use locknuts on adjustment screws.
Lubricate with ISO VG32 hydraulic oil if operating below -10℃.
| Property | Property Value |
|---|---|
| sku | SAUJ32X115-40 |
| Adjustable Stroke | <40mm> |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT1/8 |
| Magnet | Non-magnetic |
| Bore Diameter | <32 mm> |
| Stroke | 115mm |
