Airtac SAUJ32 Adjustable Stroke Cylinder SAUJ32X115-75
2. Features innovative bidirectional asymmetrical piston sealing structure with compact dimensions and integrated oil reservoir functionality;
3. Aluminum alloy tube with reinforced cross-rib design (eliminating tie rods), excellent corrosion resistance. External end incorporates sensor mounting grooves for convenient installation;
4. Compared to ISO 15662 standard cylinders, SAU series demonstrates reduced cylinder bore dimensions* and compact stroke length;
5. Precision-adjustable cushioning mechanism ensures smooth stroke termination;
6. Mounting accessories compatible with SC series cylinders for system integration flexibility;
7. High-temperature resistant sealing materials enable operational temperature range of 0-150°C.
Category: Standard Cylinders | Brand: AirTAC | Series: SAUJ32
AirTAC SAUJ32 Adjustable Stroke Cylinder SAUJ32X115-75 Technical Details
- Model Code: SAUJ32X115-75
- Cylinder Type: Double-acting adjustable stroke (mechanical stopper)
- Bore Size: Ø32 mm
- Max Stroke: 115 mm
- Adjustment Range: 0-75 mm fine-tuning capability
- Operating Pressure: 0.05-1.0 MPa
- Piston Speed: 50-1000 mm/s
- Cushioning: Rubber buffer + adjustable shock absorber
- Port Size: M5x0.8 (G1/8 adaptor included)
- Ambient Temperature: -10℃ to 70℃
- Rod Material: Chrome-plated stainless steel (SUS304)
- Body Material: Anodized aluminum alloy
- Weight: 1.85 kg (including mounting accessories)
- Dimensions:
- Extended Length: 272 mm
- Retracted Length: 157 mm
- Body Width: 52 mm
- Mounting Height: 40 mm
Precision-engineered adjustable stroke cylinder featuring dual-position mechanical stoppers for millimeter-level stroke control. The hardened aluminum construction with triple-lip seal ensures ≤0.5 mg/Nm leakage rate. Includes anti-rotation guide for stable linear motion, compatible with ISO 6432 mounting standards.
- Variable height positioning in semiconductor wafer handling
- Press tool depth adjustment systems
- Automated packaging line product ejection mechanisms
- Robotic arm end effector positioning
- Precision clamping force control in CNC fixtures
Operation Tip:
Lubricate adjustment screws monthly with ISO VG32 hydraulic oil.
For optimal performance, maintain 0.3-0.6 MPa operating pressure
and avoid lateral loads exceeding 15N. Alignment tolerance ≤0.2mm/m.
| Property | Property Value |
|---|---|
| sku | SAUJ32X115-75 |
| Adjustable Stroke | 75mm |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT1/8 |
| Magnet | Non-magnetic |
| Bore Diameter | <32 mm> |
| Stroke | 115mm |
