Airtac SAUJ32 Adjustable Stroke Cylinder SAUJ32X115-75S
2. Features innovative bidirectional asymmetrical piston sealing structure with compact dimensions and integrated oil reservoir functionality;
3. Aluminum alloy tube with reinforced cross-rib design (eliminating tie rods), excellent corrosion resistance. External end incorporates sensor mounting grooves for convenient installation;
4. Compared to ISO 15662 standard cylinders, SAU series demonstrates reduced cylinder bore dimensions* and compact stroke length;
5. Precision-adjustable cushioning mechanism ensures smooth stroke termination;
6. Mounting accessories compatible with SC series cylinders for system integration flexibility;
7. High-temperature resistant sealing materials enable operational temperature range of 0-150°C.
Category: Standard Cylinders | Brand: AirTAC | Series: SAUJ32
AirTAC SAUJ32 Adjustable Stroke Cylinder SAUJ32X115-75S Technical Details
- Model Code: SAUJ32X115-75S
- Type: Double-acting adjustable stroke cylinder
- Bore size: Ø32mm
- Full stroke: 115mm
- Adjustment range: 0-75mm (±37.5mm from center)
- Operating pressure: 0.15-0.8 MPa
- Cushioning: Adjustable rubber buffer (both ends)
- Mounting style: Basic type (no fixed mount)
- Port size: M5x0.8 (Rc1/8/NPT1/8 optional)
- Temperature range: -10℃ to 70℃
- Material:
- Tube: Aluminum alloy hard anodized
- Piston rod: SUS304 stainless steel
- Seals: NBR + PU combination
- Weight: 1.25kg (with standard accessories)
- Dimensions:
- Total length (extended): ~220mm
- Body width: 85mm (including adjustment bolts)
- Height: 85mm (port axis to base)
Precision stroke-adjustable cylinder featuring dual-side mechanical stops with 5mm incremental scales. The patented anti-rotation design maintains piston orientation during adjustment. Includes built-in locking nuts for position retention and corrosion-resistant plating on exposed metal parts. Requires ISO 8573-1:2010 class 4 compressed air.
- Variable height clamping fixtures in CNC machining centers
- Batch adjustment systems for pharmaceutical blister packaging
- Printing press roller engagement mechanisms
- Solar panel angle adjustment assemblies
- Automated conveyor gate positioning
Operation tip:
Lubricate adjustment threads monthly with ISO VG32 hydraulic oil.
Always depressurize before stroke adjustment. Maximum lateral load
capacity 150N at mid-stroke. Alignment tolerance ≤0.5mm/m.
| Property | Property Value |
|---|---|
| sku | SAUJ32X115-75S |
| Adjustable Stroke | 75mm |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT1/8 |
| Magnet | S-Magnetic |
| Bore Diameter | <32 mm> |
| Stroke | 115mm |
