Airtac SAUJ32 Adjustable Stroke Cylinder SAUJ32X120-10
$60.91
Regular price
$68.41
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
SAUJ32X120-10
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
1. Compliant with enterprise-standard cylinder specifications;
2. Features innovative bidirectional asymmetrical piston sealing structure with compact dimensions and integrated oil reservoir functionality;
3. Aluminum alloy tube with reinforced cross-rib design (eliminating tie rods), excellent corrosion resistance. External end incorporates sensor mounting grooves for convenient installation;
4. Compared to ISO 15662 standard cylinders, SAU series demonstrates reduced cylinder bore dimensions* and compact stroke length;
5. Precision-adjustable cushioning mechanism ensures smooth stroke termination;
6. Mounting accessories compatible with SC series cylinders for system integration flexibility;
7. High-temperature resistant sealing materials enable operational temperature range of 0-150°C.
Category: Standard Cylinders | Brand: AirTAC | Series: SAUJ32
Operational Guidance:
Always depressurize before adjusting stroke. Lubricate adjustment threads monthly with ISO VG32 turbine oil.
Maximum side load: 15N at full extension. For vertical mounting, use model SAUJ32X120-10V with upgraded rod lock.
Critical Note:
Avoid continuous partial stroke operation beyond 500,000 cycles without rebuffering maintenance.
Not compatible with rod-end rotational loads - use guided cylinder variants for such applications.
2. Features innovative bidirectional asymmetrical piston sealing structure with compact dimensions and integrated oil reservoir functionality;
3. Aluminum alloy tube with reinforced cross-rib design (eliminating tie rods), excellent corrosion resistance. External end incorporates sensor mounting grooves for convenient installation;
4. Compared to ISO 15662 standard cylinders, SAU series demonstrates reduced cylinder bore dimensions* and compact stroke length;
5. Precision-adjustable cushioning mechanism ensures smooth stroke termination;
6. Mounting accessories compatible with SC series cylinders for system integration flexibility;
7. High-temperature resistant sealing materials enable operational temperature range of 0-150°C.
Category: Standard Cylinders | Brand: AirTAC | Series: SAUJ32
AirTAC SAUJ32X120-10 Adjustable Stroke Air Cylinder Technical Details
- Model Code: SAUJ32X120-10 (Standard stroke version)
- Cylinder Type: Double-acting with adjustable stroke mechanism
- Bore Size: 32mm (±0.5mm tolerance)
- Maximum Stroke: 120mm (Field adjustable from 0-120mm)
- Operating Pressure: 0.05-1.0 MPa (7-145 PSI)
- Cushioning: External adjustable rubber bumper + internal air cushion
- Stroke Adjustment: Manual rotary knob with 5mm/rotation precision
- Mounting Style: Basic type (No pre-installed brackets)
- Port Size: G1/8 (BSPP thread) with NBR seals
- Temperature Range: -10℃ to 80℃ (Dry air required below 0℃)
- Tube Material: Aluminum alloy AL6063-T5 with hard anodizing
- Piston Rod: Chrome-plated steel (Cr-Mo alloy), 14mm diameter
- Weight: 1.65kg ±3% (Without accessories)
- Dimensions:
- Extended Length: 248mm (Stroke 120mm position)
- Retracted Length: 128mm
- Body Diameter: 42mm
- Mounting Hole Spacing: 25mm × 25mm square pattern
Precision-adjustable pneumatic cylinder featuring dual-position memory capability through its unique mechanical stop system. The triple-sealed design (rod seal, piston seal, and cushion seal) ensures leak-free operation in dusty environments. Includes anti-rotation guide slots for stable linear motion during partial stroke applications.
Industrial Applications:
- Variable height positioning in semiconductor wafer handling
- Packaging line product ejection force control
- Textile machinery tension adjustment systems
- Automated welding fixture stroke optimization
- 3D printer bed calibration mechanisms
Operational Guidance:
Always depressurize before adjusting stroke. Lubricate adjustment threads monthly with ISO VG32 turbine oil.
Maximum side load: 15N at full extension. For vertical mounting, use model SAUJ32X120-10V with upgraded rod lock.
Critical Note:
Avoid continuous partial stroke operation beyond 500,000 cycles without rebuffering maintenance.
Not compatible with rod-end rotational loads - use guided cylinder variants for such applications.
| Property | Property Value |
|---|---|
| sku | SAUJ32X120-10 |
| Adjustable Stroke | <10mm> |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT1/8 |
| Magnet | Non-magnetic |
| Bore Diameter | <32 mm> |
| Stroke | 120mm |
