Airtac SAUJ32 Adjustable Stroke Cylinder SAUJ32X120-100
2. Features innovative bidirectional asymmetrical piston sealing structure with compact dimensions and integrated oil reservoir functionality;
3. Aluminum alloy tube with reinforced cross-rib design (eliminating tie rods), excellent corrosion resistance. External end incorporates sensor mounting grooves for convenient installation;
4. Compared to ISO 15662 standard cylinders, SAU series demonstrates reduced cylinder bore dimensions* and compact stroke length;
5. Precision-adjustable cushioning mechanism ensures smooth stroke termination;
6. Mounting accessories compatible with SC series cylinders for system integration flexibility;
7. High-temperature resistant sealing materials enable operational temperature range of 0-150°C.
Category: Standard Cylinders | Brand: AirTAC | Series: SAUJ32
AirTAC SAUJ32X120-100 Adjustable Stroke Cylinder Specifications
- Model: SAUJ32X120-100
- Type: Double-acting adjustable stroke cylinder
- Bore size: 32mm
- Stroke range: 50-120mm (mechanically adjustable)
- Max. stroke adjustment: ±1mm precision
- Operating pressure: 0.15-0.8 MPa
- Operating temperature: -20℃ to 80℃
- Cushioning: Adjustable elastic buffer (both ends)
- Port size: G1/8 (NPT1/8 optional)
- Rod end thread: M12×1.25
- Material: Aluminum alloy body, chrome-plated piston rod
- Seal material: NBR (Nitrile rubber)
- Weight: 1.65kg (excluding accessories)
- Dimensions:
- Extended length: 246mm (at 120mm stroke)
- Retracted length: 126mm
- Body diameter: 42mm
- Mounting base: 32×32mm square pattern
- ISO standard: 6431 (VDMA 24562)
- Protection rating: IP54 (standard), IP67 (optional w/rod cover)
Precision-adjustable pneumatic cylinder featuring dual mechanical stroke limiters with locknuts for stable positioning. The integrated buffer adjustment screws allow fine-tuning of end-position damping. Anodized surface treatment provides corrosion resistance for humid environments. Includes auto-switch mounting grooves for sensor compatibility.
- Variable height positioning in packaging lines
- Precision clamping force adjustment in CNC fixtures
- Material feeding systems with adjustable stroke requirements
- Textile machinery tension control mechanisms
- Automated door stroke adjustment in cleanrooms
Installation note:
Use anti-rotation brackets (optional AR-32 accessory) when mounting in orientation-sensitive applications.
Lubricate with ISO VG32 hydraulic oil during initial setup. Max lateral load: 15N at full extension.
| Property | Property Value |
|---|---|
| sku | SAUJ32X120-100 |
| Adjustable Stroke | 100mm |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT1/8 |
| Magnet | Non-magnetic |
| Bore Diameter | <32 mm> |
| Stroke | 120mm |
