Airtac SAUJ32 Adjustable Stroke Cylinder SAUJ32X120-100S
2. Features innovative bidirectional asymmetrical piston sealing structure with compact dimensions and integrated oil reservoir functionality;
3. Aluminum alloy tube with reinforced cross-rib design (eliminating tie rods), excellent corrosion resistance. External end incorporates sensor mounting grooves for convenient installation;
4. Compared to ISO 15662 standard cylinders, SAU series demonstrates reduced cylinder bore dimensions* and compact stroke length;
5. Precision-adjustable cushioning mechanism ensures smooth stroke termination;
6. Mounting accessories compatible with SC series cylinders for system integration flexibility;
7. High-temperature resistant sealing materials enable operational temperature range of 0-150°C.
Category: Standard Cylinders | Brand: AirTAC | Series: SAUJ32
AirTAC SAUJ32X120-100S Adjustable Stroke Cylinder Specifications
- Model: SAUJ32X120-100S
- Type: Double-acting adjustable stroke cylinder
- Bore size: 32mm
- Stroke: 120mm
- Adjustment range: 0-100mm (mechanical stopper)
- Operating pressure: 0.05-1.0 MPa
- Cushion type: Rubber buffer + external adjustment
- Mounting style: Standard ISO/VDS bracket
- Port size: M5x0.8 (G1/8 adaptor optional)
- Operating temperature: -10℃ to 80℃
- Piston material: Aluminum alloy (hard anodized)
- Rod material: Chrome-plated steel
- Seal type: NBR seals
- Weight: ~1.8kg (without accessories)
- Dimensions:
- Extended length: 248mm (max)
- Retracted length: 148mm (min)
- Body width: 50mm
- Mounting height: 32mm
Precision-adjustable pneumatic cylinder featuring dual-position mechanical stops for mid-stroke positioning. The external stroke adjustment mechanism enables ±0.5mm repeatability without disassembly. Integrated cushioning system reduces impact noise by 30% compared to standard models. Compatible with auto-switch sensors (slot width 18mm).
- Precision clamping fixtures in CNC machining
- Variable height positioning in conveyor systems
- Material handling with adjustable gripping depth
- Packaging machine stroke compensation
- Automated test equipment with multi-position stops
Operation tip: Lubricate adjustment threads monthly with ISO VG32 hydraulic oil.
Avoid over-tightening position locks - maximum torque 2.5N·m.
For vertical installations, use model with built-in anti-rotation guide.
| Property | Property Value |
|---|---|
| sku | SAUJ32X120-100S |
| Adjustable Stroke | 100mm |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT1/8 |
| Magnet | S-Magnetic |
| Bore Diameter | <32 mm> |
| Stroke | 120mm |
