Airtac SAUJ32 Adjustable Stroke Cylinder SAUJ32X120-10S
$63.70
Regular price
$71.20
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
SAUJ32X120-10S
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
1. Compliant with enterprise-standard cylinder specifications;
2. Features innovative bidirectional asymmetrical piston sealing structure with compact dimensions and integrated oil reservoir functionality;
3. Aluminum alloy tube with reinforced cross-rib design (eliminating tie rods), excellent corrosion resistance. External end incorporates sensor mounting grooves for convenient installation;
4. Compared to ISO 15662 standard cylinders, SAU series demonstrates reduced cylinder bore dimensions* and compact stroke length;
5. Precision-adjustable cushioning mechanism ensures smooth stroke termination;
6. Mounting accessories compatible with SC series cylinders for system integration flexibility;
7. High-temperature resistant sealing materials enable operational temperature range of 0-150°C.
Category: Standard Cylinders | Brand: AirTAC | Series: SAUJ32
Installation Guidelines:
Maintain 0.5-1mm alignment tolerance during mounting. Lubricate with ISO VG32 hydraulic oil
(1-2 drops per port). For vertical installations, use the anti-vibration locknut (AV-32 accessory sold separately).
Maximum side load: 15N at full extension.
2. Features innovative bidirectional asymmetrical piston sealing structure with compact dimensions and integrated oil reservoir functionality;
3. Aluminum alloy tube with reinforced cross-rib design (eliminating tie rods), excellent corrosion resistance. External end incorporates sensor mounting grooves for convenient installation;
4. Compared to ISO 15662 standard cylinders, SAU series demonstrates reduced cylinder bore dimensions* and compact stroke length;
5. Precision-adjustable cushioning mechanism ensures smooth stroke termination;
6. Mounting accessories compatible with SC series cylinders for system integration flexibility;
7. High-temperature resistant sealing materials enable operational temperature range of 0-150°C.
Category: Standard Cylinders | Brand: AirTAC | Series: SAUJ32
AirTAC SAUJ32 Adjustable Stroke Cylinder SAUJ32X120-10S Technical Details
- Model Code: SAUJ32X120-10S
- Bore Size: 32mm (ISO 6432 standard)
- Stroke Length: 120mm (±0.5mm adjustment range)
- Operation Type: Double-acting with adjustable cushioning
- Working Pressure: 0.05-1.0 MPa (7-145 PSI)
- Ambient Temperature: -10℃ to 70℃ (14°F to 158°F)
- Piston Speed: 50-800 mm/s (with cushion engaged)
- Port Thread: G1/8 (BSPP) dual ports
- Rod End: M12×1.25 external thread
- Mounting Style: Basic type (MF1 pattern per ISO 15552)
- Seal Material: NBR + PU combination
- Body Material: Aluminum alloy (anodized finish)
- Weight: 1.25kg (without accessories)
- Dimensions: 202mm(L) × 42mm(W) × 42mm(H) (extended length)
Precision-adjustable pneumatic cylinder featuring dual-stage shock absorption with 360° rotatable cushion needles. The SAUJ32 series incorporates a unique stroke adjustment mechanism with positive lock nuts, enabling micron-level positioning repeatability. Corrosion-resistant construction with IP54 splash protection.
Industrial Applications:
- Precision clamping fixtures in CNC machining centers
- Variable height positioning in semiconductor handling robots
- Adjustable press mechanisms for electronic component assembly
- Material feeding systems requiring stroke adaptation
- Packaging line product height compensation units
Installation Guidelines:
Maintain 0.5-1mm alignment tolerance during mounting. Lubricate with ISO VG32 hydraulic oil
(1-2 drops per port). For vertical installations, use the anti-vibration locknut (AV-32 accessory sold separately).
Maximum side load: 15N at full extension.
| Property | Property Value |
|---|---|
| sku | SAUJ32X120-10S |
| Adjustable Stroke | <10mm> |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT1/8 |
| Magnet | S-Magnetic |
| Bore Diameter | <32 mm> |
| Stroke | 120mm |
