Airtac SAUJ32 Adjustable Stroke Cylinder SAUJ32X120-20
$60.91
Regular price
$68.41
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
SAUJ32X120-20
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
1. Compliant with enterprise-standard cylinder specifications;
2. Features innovative bidirectional asymmetrical piston sealing structure with compact dimensions and integrated oil reservoir functionality;
3. Aluminum alloy tube with reinforced cross-rib design (eliminating tie rods), excellent corrosion resistance. External end incorporates sensor mounting grooves for convenient installation;
4. Compared to ISO 15662 standard cylinders, SAU series demonstrates reduced cylinder bore dimensions* and compact stroke length;
5. Precision-adjustable cushioning mechanism ensures smooth stroke termination;
6. Mounting accessories compatible with SC series cylinders for system integration flexibility;
7. High-temperature resistant sealing materials enable operational temperature range of 0-150°C.
Category: Standard Cylinders | Brand: AirTAC | Series: SAUJ32
Installation note:
Use locknuts (M10) with 12-15Nm torque for stroke adjustment.
Lubricate guide shafts with ISO VG32 hydraulic oil monthly.
Maintain 0.3mm minimum clearance between stopper plates during adjustment.
2. Features innovative bidirectional asymmetrical piston sealing structure with compact dimensions and integrated oil reservoir functionality;
3. Aluminum alloy tube with reinforced cross-rib design (eliminating tie rods), excellent corrosion resistance. External end incorporates sensor mounting grooves for convenient installation;
4. Compared to ISO 15662 standard cylinders, SAU series demonstrates reduced cylinder bore dimensions* and compact stroke length;
5. Precision-adjustable cushioning mechanism ensures smooth stroke termination;
6. Mounting accessories compatible with SC series cylinders for system integration flexibility;
7. High-temperature resistant sealing materials enable operational temperature range of 0-150°C.
Category: Standard Cylinders | Brand: AirTAC | Series: SAUJ32
AirTAC SAUJ32X120-20 Adjustable Cylinder Specifications
- Model: SAUJ32X120-20
- Series: SAUJ (Adjustable Stroke Compact Cylinder)
- Bore size: 32mm
- Stroke: 120mm (±20mm adjustable range)
- Operating pressure: 0.05–1.0 MPa
- Piston speed: 50–800 mm/s
- Cushioning: Adjustable rubber buffer + air cushion
- Mounting type: Basic type (optional accessories: MF1~MF8 brackets)
- Port size: Rc1/8 (G1/8 optional)
- Ambient temperature: -20℃ to 80℃
- Material: Aluminum alloy barrel, CRMo steel piston rod
- Seal type: NBR seals (optional FKM for high temp)
- Weight: 2.3kg (without accessories)
- Dimensions: 200mm(L) × 80mm(W) × 80mm(H) (full extension)
- Rod end type: Male thread M10×1.25
- Protection class: IP54 (standard), IP67 (optional)
Precision-adjustable compact cylinder featuring dual-position mechanical locking for stroke adjustment (±20mm). Equipped with anti-rotation guide mechanism and dual cushioning system. Special chrome-plated piston rod with wear-resistant coating (3-5μm) ensures 3,000km+ service life.
Typical Applications:
- Precision positioning in semiconductor handling robots
- Variable height adjustment in packaging sealing machines
- Tooling fixture positioning for CNC machining centers
- Material feeding systems with adjustable stroke requirements
- Automated door stop mechanisms in cleanroom environments
Installation note:
Use locknuts (M10) with 12-15Nm torque for stroke adjustment.
Lubricate guide shafts with ISO VG32 hydraulic oil monthly.
Maintain 0.3mm minimum clearance between stopper plates during adjustment.
| Property | Property Value |
|---|---|
| sku | SAUJ32X120-20 |
| Adjustable Stroke | <20mm> |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT1/8 |
| Magnet | Non-magnetic |
| Bore Diameter | <32 mm> |
| Stroke | 120mm |
