Airtac SAUJ40 Adjustable Stroke Cylinder SAUJ40X10-10
$57.65
Regular price
$65.15
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
SAUJ40X10-10
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
1. Enterprise-standard cylinder compliant with internal specifications;
2. Features custom bidirectional seal profile for piston sealing with compact dimensions and integrated oil reservoir;
3. Aluminum tube with octagonal pattern design, rodless construction. Enhanced corrosion resistance; Integrated external sensor mounting grooves for simplified installation;
4. Compared to ISO 15662 standard cylinders, SAU series demonstrates shorter stroke length at equivalent bore sizes;
5. Precision-engineered smooth cushioning adjustment mechanism;
6. Full compatibility with SC series cylinder mounting accessories;
7. High-temperature resistant sealing materials implemented, operational range: 0-150°C.
Category: Standard Cylinders | Brand: AirTAC | Series: SAUJ40
Installation guidance:
Maximum lateral load 15N. For vertical mounting, use counterbalance valves.
Lubricate with ISO VG32 hydraulic oil if operating below 0.3 MPa. Adjustment
should be made in depressurized state - turn clockwise to reduce stroke.
2. Features custom bidirectional seal profile for piston sealing with compact dimensions and integrated oil reservoir;
3. Aluminum tube with octagonal pattern design, rodless construction. Enhanced corrosion resistance; Integrated external sensor mounting grooves for simplified installation;
4. Compared to ISO 15662 standard cylinders, SAU series demonstrates shorter stroke length at equivalent bore sizes;
5. Precision-engineered smooth cushioning adjustment mechanism;
6. Full compatibility with SC series cylinder mounting accessories;
7. High-temperature resistant sealing materials implemented, operational range: 0-150°C.
Category: Standard Cylinders | Brand: AirTAC | Series: SAUJ40
AirTAC SAUJ40X10-10 Adjustable Cylinder Technical Details
- Model: SAUJ40X10-10
- Type: Double-acting adjustable stroke cylinder
- Bore size: 40mm (ISO 6432 standard)
- Stroke: 10mm (adjustable range: 0-10mm)
- Operating pressure: 0.05-1.0 MPa
- Adjustment mechanism: External threaded stopper with lock nut
- Cushion type: Elastic rubber + adjustable cushioning
- Port size: M5x0.8 (standard) / NPT1/8 optional
- Rod end: Female thread M10x1.25
- Material: Aluminum alloy barrel (hard anodized), stainless steel piston rod
- Seal material: NBR + PU combination
- Temperature range: -20℃ to 80℃
- Weight: 0.68kg (without accessories)
- Dimensions: 116mm(L) × 40mm(Bore) × 40mm(Mounting width)
- Stroke tolerance: ±1.5mm
- Max speed: 500mm/s
- Protection rating: IP54 (standard sealing)
Precision micro-stroke cylinder with mechanical position locking, featuring dual cushioning system for smooth end-of-stroke deceleration. The chrome-plated piston rod with integrated scraper ring prevents contamination ingress. Requires ISO 8573-1:2010 Class 3-4-3 compressed air quality.
Common Applications:
- Precision material feeding mechanisms
- Electronics assembly press-fit operations
- Medical device positioning systems
- Printing machine tension control
- Semiconductor wafer handling
- Automated test equipment with stroke variation needs
Installation guidance:
Maximum lateral load 15N. For vertical mounting, use counterbalance valves.
Lubricate with ISO VG32 hydraulic oil if operating below 0.3 MPa. Adjustment
should be made in depressurized state - turn clockwise to reduce stroke.
| Property | Property Value |
|---|---|
| sku | SAUJ40X10-10 |
| Adjustable Stroke | <10mm> |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT1/4 |
| Magnet | Non-magnetic |
| Bore Diameter | <40mm> |
| Stroke | <10mm> |
