Airtac SAUJ40 Adjustable Stroke Cylinder SAUJ40X10-10S
2. Features custom bidirectional seal profile for piston sealing with compact dimensions and integrated oil reservoir;
3. Aluminum tube with octagonal pattern design, rodless construction. Enhanced corrosion resistance; Integrated external sensor mounting grooves for simplified installation;
4. Compared to ISO 15662 standard cylinders, SAU series demonstrates shorter stroke length at equivalent bore sizes;
5. Precision-engineered smooth cushioning adjustment mechanism;
6. Full compatibility with SC series cylinder mounting accessories;
7. High-temperature resistant sealing materials implemented, operational range: 0-150°C.
Category: Standard Cylinders | Brand: AirTAC | Series: SAUJ40
AirTAC SAUJ40X10-10S Adjustable Stroke Cylinder Specifications
- Model: SAUJ40X10-10S
- Type: Double-acting adjustable stroke cylinder
- Bore size: 40mm
- Stroke range: 10-100mm (mechanically adjustable)
- Operating pressure: 0.1–0.9 MPa
- Cushioning: Adjustable rubber buffer at both ends
- Port size: Rc1/4 (G1/4 optional)
- Rod diameter: 16mm
- Mounting type: Front flange (ISO 15552 standard)
- Material: Aluminum alloy body, chrome-plated piston rod
- Seal material: NBR (Nitrile rubber)
- Temperature range: -20℃ to 80℃
- Weight: 1.2kg ±5%
- Dimensions (L×W×H): 158mm × 40mm × 40mm (minimum retracted length)
- Max thrust: 502N @0.6MPa (extending)
- Speed range: 50–800mm/s
- Lubrication: Pre-lubricated (oil-free operation possible)
Precision-adjustable pneumatic cylinder featuring a unique mechanical stroke adjustment mechanism with positive locking. The dual-scale position indicator (metric/imperial) allows micron-level positioning accuracy. Corrosion-resistant construction with IP54 protection rating makes it suitable for harsh environments.
- Precision clamping fixtures in CNC machining centers
- Variable height positioning in packaging lines
- Pressure-sensitive assembly processes (e.g., electronics manufacturing)
- Material handling systems requiring adjustable stroke profiles
- Automated test equipment with space constraints
Installation note:
Use locknuts (M5×0.8) for stroke limiter fixation. For vertical mounting,
maintain ≥0.3MPa residual pressure to prevent piston rod sagging. Lubricate
adjustment threads monthly with ISO VG32 hydraulic oil.
| Property | Property Value |
|---|---|
| sku | SAUJ40X10-10S |
| Adjustable Stroke | <10mm> |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT1/4 |
| Magnet | S-Magnetic |
| Bore Diameter | <40mm> |
| Stroke | <10mm> |
