Airtac SAUJ40 Adjustable Stroke Cylinder SAUJ40X100-10
$63.50
Regular price
$71.00
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
SAUJ40X100-10
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
1. Enterprise-standard cylinder compliant with internal specifications;
2. Features custom bidirectional seal profile for piston sealing with compact dimensions and integrated oil reservoir;
3. Aluminum tube with octagonal pattern design, rodless construction. Enhanced corrosion resistance; Integrated external sensor mounting grooves for simplified installation;
4. Compared to ISO 15662 standard cylinders, SAU series demonstrates shorter stroke length at equivalent bore sizes;
5. Precision-engineered smooth cushioning adjustment mechanism;
6. Full compatibility with SC series cylinder mounting accessories;
7. High-temperature resistant sealing materials implemented, operational range: 0-150°C.
Category: Standard Cylinders | Brand: AirTAC | Series: SAUJ40
Maintenance Protocol:
Lubricate with ISO VG32 hydraulic oil monthly. Avoid side load exceeding 15N.
For vertical mounting, use tandem cylinder brackets (sold separately).
Cushion adjustment requires 2.5mm hex key (included).
2. Features custom bidirectional seal profile for piston sealing with compact dimensions and integrated oil reservoir;
3. Aluminum tube with octagonal pattern design, rodless construction. Enhanced corrosion resistance; Integrated external sensor mounting grooves for simplified installation;
4. Compared to ISO 15662 standard cylinders, SAU series demonstrates shorter stroke length at equivalent bore sizes;
5. Precision-engineered smooth cushioning adjustment mechanism;
6. Full compatibility with SC series cylinder mounting accessories;
7. High-temperature resistant sealing materials implemented, operational range: 0-150°C.
Category: Standard Cylinders | Brand: AirTAC | Series: SAUJ40
AirTAC SAUJ40 Adjustable Cylinder SAUJ40X100-10 Technical Details
- Model Code Breakdown: SAUJ40X100-10
- SAUJ: Adjustable stroke cylinder series
- 40: Bore size (40mm)
- X100: Stroke length 100mm (adjustable range ±1mm)
- -10: Cushioning type (adjustable pneumatic cushion)
- Bore Diameter: 40mm (±0.1mm)
- Stroke Tolerance: 0~+1.5mm
- Operating Pressure: 0.1-0.9 MPa
- Ambient Temperature: -20℃ to +80℃
- Piston Speed: 50-800 mm/s (optimal at 200-500 mm/s)
- Mounting Style: Basic type (foot-mounted) with ISO 15552 standard
- Port Size: G1/8 (BSPP thread)
- Rod Thread: M16×1.5 (external)
- Cushion Adjustment: 5-20mm turn range (clockwise for softer stop)
- Weight: 1.25kg (excluding accessories)
- Dimensions:
- Extended Length: 248mm (stroke 100mm + base length)
- Retracted Length: 148mm
- Body Diameter: Φ40mm
- Mounting Hole Spacing: 30mm (vertical) × 18mm (horizontal)
- Material Construction:
- Tube: Aluminum alloy (hard anodized)
- Piston Rod: Chrome-plated steel (Cr-Mo alloy)
- Seals: NBR (nitrile) standard / Optional FKM (fluorocarbon)
- Sensor Compatibility: Magnetic switch D-M9N/D-A9N (mounting groove included)
Precision-engineered adjustable stroke cylinder featuring dual-side cushion control and IP65 protection rating. The SAUJ series incorporates a unique anti-rotation mechanism (patented guide slot design) for stable linear motion. Includes built-in stroke adjustment lock nuts and wear-resistant rod scraper. Requires ISO 8573-1:2010 Class 3 compressed air.
Industrial Applications:
- Position-sensitive press tooling systems
- Variable height clamping in CNC fixtures
- Packaging line product height compensation
- Automated door stroke adjustment mechanisms
- Plastic injection mold core pulling
Maintenance Protocol:
Lubricate with ISO VG32 hydraulic oil monthly. Avoid side load exceeding 15N.
For vertical mounting, use tandem cylinder brackets (sold separately).
Cushion adjustment requires 2.5mm hex key (included).
| Property | Property Value |
|---|---|
| sku | SAUJ40X100-10 |
| Adjustable Stroke | <10mm> |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT1/4 |
| Magnet | Non-magnetic |
| Bore Diameter | <40mm> |
| Stroke | 100mm |
