Airtac SAUJ40 Adjustable Stroke Cylinder SAUJ40X100-100S
2. Features custom bidirectional seal profile for piston sealing with compact dimensions and integrated oil reservoir;
3. Aluminum tube with octagonal pattern design, rodless construction. Enhanced corrosion resistance; Integrated external sensor mounting grooves for simplified installation;
4. Compared to ISO 15662 standard cylinders, SAU series demonstrates shorter stroke length at equivalent bore sizes;
5. Precision-engineered smooth cushioning adjustment mechanism;
6. Full compatibility with SC series cylinder mounting accessories;
7. High-temperature resistant sealing materials implemented, operational range: 0-150°C.
Category: Standard Cylinders | Brand: AirTAC | Series: SAUJ40
AirTAC SAUJ40X100-100S Adjustable Stroke Cylinder Specifications
- Model: SAUJ40X100-100S
- Type: Double-acting adjustable stroke cylinder
- Bore size: 40mm
- Stroke: 100mm
- Adjustment range: 0-100mm (continuous position locking)
- Operating pressure: 0.1-0.8 MPa
- Cushioning type: Adjustable air cushion at both ends
- Mounting style: Basic type (MF1)
- Port size: PT1/8 (G1/8 optional)
- Temperature range: -20℃ to 80℃
- Material:
- Tube: Aluminum alloy (hard anodized)
- Piston rod: SUS304 stainless steel
- Seals: NBR + PU combination
- Weight: 2.3kg ±5%
- Dimensions:
- Total length: 200mm (min) - 300mm (max extended)
- Body width: 58mm
- Height with mounting: 72mm
- Rod end thread: M10×1.25
Precision-adjustable pneumatic cylinder featuring patented mechanical locking mechanism for mid-stroke positioning. The SAUJ series combines position flexibility with cylinder rigidity, using corrosion-resistant materials and dual cushioning for smooth operation. Requires 5μm filtered air and regular lubrication (ISO VG32).
- Variable height work platforms in assembly lines
- Precision clamping force adjustment systems
- Material handling with position-sensitive gripping
- Automated packaging length adjustment units
- Semiconductor wafer handling equipment
Installation tip:
Use precision alignment jigs during mounting to prevent side load.
For full stroke adjustment capability, maintain 15mm clearance
behind the cylinder for adjustment tool access.
| Property | Property Value |
|---|---|
| sku | SAUJ40X100-100S |
| Adjustable Stroke | 100mm |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT1/4 |
| Magnet | S-Magnetic |
| Bore Diameter | <40mm> |
| Stroke | 100mm |
