Airtac SAUJ40 Adjustable Stroke Cylinder SAUJ40X100-10S
2. Features custom bidirectional seal profile for piston sealing with compact dimensions and integrated oil reservoir;
3. Aluminum tube with octagonal pattern design, rodless construction. Enhanced corrosion resistance; Integrated external sensor mounting grooves for simplified installation;
4. Compared to ISO 15662 standard cylinders, SAU series demonstrates shorter stroke length at equivalent bore sizes;
5. Precision-engineered smooth cushioning adjustment mechanism;
6. Full compatibility with SC series cylinder mounting accessories;
7. High-temperature resistant sealing materials implemented, operational range: 0-150°C.
Category: Standard Cylinders | Brand: AirTAC | Series: SAUJ40
AirTAC SAUJ40X100-10S Adjustable Cylinder Specifications
- Model: SAUJ40X100-10S
- Type: Double-acting adjustable stroke cylinder
- Bore size: 40mm
- Stroke: 100mm (adjustable via external stopper)
- Operating pressure: 0.1–0.9 MPa
- Cushioning: Adjustable pneumatic cushion at both ends
- Mounting style: Front pivot bracket (ISO 15552 standard)
- Port size: M5x0.8 (G1/8 adaptor included)
- Material: Aluminum alloy barrel, chromium-plated piston rod
- Seal material: NBR (Nitrile rubber)
- Temperature range: -20℃ to 80℃
- Weight: 1.65kg ±3%
- Dimensions:
- Total length (extended): 240mm
- Body diameter: 50mm
- Mounting bracket width: 85mm
- Rod end thread: M10x1.25
- Cycle rate: ≤3 cycles/sec (with cushion engaged)
- IP rating: IP54 (standard seals)
High-precision adjustable stroke cylinder featuring dual-position locking mechanism for mid-stroke positioning. The through-rod design allows external stroke adjustment via hexagonal wrench (included). Integrated cushioning valves enable precise end-position deceleration control, reducing impact noise by 40% compared to basic models.
- Variable height positioning in packaging machinery
- Precision clamping devices with adjustable pressure
- Automated assembly line stop mechanisms
- Textile machinery with variable stroke requirements
- Semiconductor handling equipment
Operation tip:
For optimal performance, lubricate the adjustment threads monthly with ISO VG32 hydraulic oil.
Maximum allowable side load: 15N at full extension. Always engage both locking nuts after stroke adjustment.
| Property | Property Value |
|---|---|
| sku | SAUJ40X100-10S |
| Adjustable Stroke | <10mm> |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT1/4 |
| Magnet | S-Magnetic |
| Bore Diameter | <40mm> |
| Stroke | 100mm |
