Airtac SAUJ40 Adjustable Stroke Cylinder SAUJ40X100-20
$63.50
Regular price
$71.00
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
SAUJ40X100-20
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
1. Enterprise-standard cylinder compliant with internal specifications;
2. Features custom bidirectional seal profile for piston sealing with compact dimensions and integrated oil reservoir;
3. Aluminum tube with octagonal pattern design, rodless construction. Enhanced corrosion resistance; Integrated external sensor mounting grooves for simplified installation;
4. Compared to ISO 15662 standard cylinders, SAU series demonstrates shorter stroke length at equivalent bore sizes;
5. Precision-engineered smooth cushioning adjustment mechanism;
6. Full compatibility with SC series cylinder mounting accessories;
7. High-temperature resistant sealing materials implemented, operational range: 0-150°C.
Category: Standard Cylinders | Brand: AirTAC | Series: SAUJ40
Maintenance Tip:
Perform cushion needle adjustment clockwise for softer stops (reduce counter-pressure)
and counter-clockwise for firmer endpoint positioning. Lubricate adjustment screws
monthly with silicone grease (AS-20 specification).
2. Features custom bidirectional seal profile for piston sealing with compact dimensions and integrated oil reservoir;
3. Aluminum tube with octagonal pattern design, rodless construction. Enhanced corrosion resistance; Integrated external sensor mounting grooves for simplified installation;
4. Compared to ISO 15662 standard cylinders, SAU series demonstrates shorter stroke length at equivalent bore sizes;
5. Precision-engineered smooth cushioning adjustment mechanism;
6. Full compatibility with SC series cylinder mounting accessories;
7. High-temperature resistant sealing materials implemented, operational range: 0-150°C.
Category: Standard Cylinders | Brand: AirTAC | Series: SAUJ40
AirTAC SAUJ40X100-20 Adjustable Stroke Cylinder Technical Details
- Full Model: SAUJ40X100-20
- Bore Size: 40mm (ISO 6432 standard)
- Stroke Length: 100mm (±0.5mm tolerance)
- Adjustment Range: ±5° angular adjustment via hex wrench
- Operating Pressure: 0.15-1.0 MPa (21-145 PSI)
- Piston Speed: 50-800 mm/s (lubricated condition)
- Cushioning: Adjustable air cushion at both ends
- Mounting: MF1/MF2 standard mounts (optional)
- Rod Thread: M20×1.5 external thread (ISO 12240-1)
- Ambient Temp: -20℃ to +80℃ (NBR seals)
- Weight: 1.65kg ±3% (without accessories)
- Dimensions: 200mm(L) × 56mm(W) × 56mm(H) (extended length)
- Port Size: G1/8 (BSPP) dual ports
- Rod End: Female thread + cushion screw
- Repeat Accuracy: ±0.2mm (under 0.5MPa)
- IP Rating: IP54 (standard wiper seal)
Precision-adjustable compact cylinder featuring dual-axis position locking mechanism with graduated scale. The anodized aluminum body incorporates wear-resistant guide bands and shock-absorbing bumpers. Requires ISO VG32 hydraulic oil mist lubrication (0.1cm³/min minimum) for optimal performance.
Industrial Applications:
- PCB depaneling machine positioning arms
- Automated screw driving torque control systems
- Glass panel vacuum lifting alignment
- Textile machinery thread tension adjustment
- Pharmaceutical blister packaging depth control
Maintenance Tip:
Perform cushion needle adjustment clockwise for softer stops (reduce counter-pressure)
and counter-clockwise for firmer endpoint positioning. Lubricate adjustment screws
monthly with silicone grease (AS-20 specification).
Configuration Options:
- Magnetic piston version available (SAUJ40X100-20/M)
- High-temp variant with FKM seals (-HT suffix)
- Rod guard kits for particulate-heavy environments
- Custom stroke lengths: 25-300mm (2mm increment)
| Property | Property Value |
|---|---|
| sku | SAUJ40X100-20 |
| Adjustable Stroke | <20mm> |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT1/4 |
| Magnet | Non-magnetic |
| Bore Diameter | <40mm> |
| Stroke | 100mm |
