Airtac SAUJ40 Adjustable Stroke Cylinder SAUJ40X100-20S
2. Features custom bidirectional seal profile for piston sealing with compact dimensions and integrated oil reservoir;
3. Aluminum tube with octagonal pattern design, rodless construction. Enhanced corrosion resistance; Integrated external sensor mounting grooves for simplified installation;
4. Compared to ISO 15662 standard cylinders, SAU series demonstrates shorter stroke length at equivalent bore sizes;
5. Precision-engineered smooth cushioning adjustment mechanism;
6. Full compatibility with SC series cylinder mounting accessories;
7. High-temperature resistant sealing materials implemented, operational range: 0-150°C.
Category: Standard Cylinders | Brand: AirTAC | Series: SAUJ40
AirTAC SAUJ40 Adjustable Cylinder SAUJ40X100-20S Technical Details
- Model: SAUJ40X100-20S
- Type: Double-acting adjustable stroke cylinder
- Bore size: 40mm
- Stroke: 100mm (adjustable)
- Adjustment range: 0-20mm stroke reduction
- Operating pressure: 0.05-1.0 MPa
- Cushioning: Dual adjustable rubber buffers
- Mounting type: Standard front flange (MF1) with side mounting holes
- Port size: M5x0.8 (G1/8 adapter optional)
- Operating temperature: -10℃ to 80℃
- Piston material: Aluminum alloy with hard anodizing
- Rod material: Chrome-plated steel (Cr-Mo)
- Seal type: NBR seals with wear-resistant ring
- Weight: 1.45kg ±3%
- Dimensions: 185mm(L) × 52mm(W) × 52mm(H)
- Repeat positioning accuracy: ±0.2mm
- Max speed: 500mm/s
Precision-adjustable pneumatic cylinder featuring mechanical stroke adjustment mechanism with locking nut. The SAUJ40 series combines position flexibility with robust construction, offering 5-stage position memory through its rotary adjustment dial. Corrosion-resistant design with IP54 protection rating makes it suitable for humid environments.
- Variable clamping force fixtures in CNC machining centers
- Position-adjustable stoppers in assembly lines
- Press tool height compensation systems
- Packaging machine product size adaptation
- Semiconductor handling equipment with Z-axis fine-tuning
Operation tip:
Always depressurize before adjusting stroke. Use locking pliers on the
adjustment rod while tightening the lock nut to prevent position drift.
Lubricate adjustment threads monthly with ISO VG32 hydraulic oil.
- Allow 15mm clearance around adjustment mechanism
- Max lateral load: 35N at full extension
- Use M5x0.8 12.9 grade mounting screws
- Align within 0.2mm/m perpendicularity tolerance
| Property | Property Value |
|---|---|
| sku | SAUJ40X100-20S |
| Adjustable Stroke | <20mm> |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT1/4 |
| Magnet | S-Magnetic |
| Bore Diameter | <40mm> |
| Stroke | 100mm |
