Airtac SAUJ40 Adjustable Stroke Cylinder SAUJ40X100-30
2. Features custom bidirectional seal profile for piston sealing with compact dimensions and integrated oil reservoir;
3. Aluminum tube with octagonal pattern design, rodless construction. Enhanced corrosion resistance; Integrated external sensor mounting grooves for simplified installation;
4. Compared to ISO 15662 standard cylinders, SAU series demonstrates shorter stroke length at equivalent bore sizes;
5. Precision-engineered smooth cushioning adjustment mechanism;
6. Full compatibility with SC series cylinder mounting accessories;
7. High-temperature resistant sealing materials implemented, operational range: 0-150°C.
Category: Standard Cylinders | Brand: AirTAC | Series: SAUJ40
AirTAC SAUJ40 Adjustable Cylinder SAUJ40X100-30 Technical Details
- Model: SAUJ40X100-30
- Type: Double-acting adjustable stroke cylinder
- Bore size: 40mm
- Stroke: 100mm (adjustable)
- Operating pressure: 0.05–1.0 MPa
- Cushioning type: External adjustable rubber bumper
- Mounting style: Basic MF1 (front flange) with standard accessories
- Port size: 1/4" NPT (G1/8 optional)
- Operating temperature: -10℃ to 80℃
- Material:
- Tube: Aluminum alloy (hard anodized)
- Piston rod: Chrome-plated stainless steel (SUS304)
- Seals: NBR (nitrile rubber)
- Weight: 1.8kg ±5% (without accessories)
- Dimensions:
- Extended length: 237mm
- Retracted length: 137mm
- Body diameter: Φ40mm
- Mounting hole spacing: 32mm × 32mm
Precision-engineered adjustable stroke cylinder featuring micro-positioning capability (±0.5mm repeat accuracy). The external cushion adjustment mechanism allows fine-tuning of end-position damping force (0.5-3N·m torque range). Integrated magnetic piston enables position feedback when used with sensors (not included).
- Precision workpiece clamping in CNC fixtures
- Variable stroke applications in packaging line diverters
- Adjustable press mechanisms for electronic component assembly
- Material handling systems requiring position flexibility
Operation guidance:
Adjust cushion screws clockwise to increase damping force. Lubricate with ISO VG32 hydraulic oil
if used without air line lubricator. Maximum side load capacity: 15N at full extension.
| Property | Property Value |
|---|---|
| sku | SAUJ40X100-30 |
| Adjustable Stroke | 30mm |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT1/4 |
| Magnet | Non-magnetic |
| Bore Diameter | <40mm> |
| Stroke | 100mm |
