Airtac SAUJ40 Adjustable Stroke Cylinder SAUJ40X100-40
2. Features custom bidirectional seal profile for piston sealing with compact dimensions and integrated oil reservoir;
3. Aluminum tube with octagonal pattern design, rodless construction. Enhanced corrosion resistance; Integrated external sensor mounting grooves for simplified installation;
4. Compared to ISO 15662 standard cylinders, SAU series demonstrates shorter stroke length at equivalent bore sizes;
5. Precision-engineered smooth cushioning adjustment mechanism;
6. Full compatibility with SC series cylinder mounting accessories;
7. High-temperature resistant sealing materials implemented, operational range: 0-150°C.
Category: Standard Cylinders | Brand: AirTAC | Series: SAUJ40
AirTAC SAUJ40X100-40 Adjustable Stroke Cylinder Specifications
- Model: SAUJ40X100-40
- Type: Adjustable stroke single-acting cylinder (spring return)
- Bore size: 40mm
- Stroke range: 10-100mm (mechanically adjustable)
- Operating pressure: 0.05-0.8 MPa
- Cushioning: Adjustable rubber buffer
- Mounting style: Basic type (MF1) with front thread M10×1.25
- Operating temperature: -20℃ to 80℃
- Material: Aluminum alloy barrel, chrome-plated piston rod
- Seal material: NBR (nitrile rubber)
- Port size: M5×0.8 (Rc1/8 optional)
- Weight: 1.65kg ±2%
- Dimensions: 200mm(L) × 50mm(W) × 50mm(H) (max extended length)
- Rod thread: M10×1.25 external thread
- Protection rating: IP54 (standard wiper seal)
Precision-adjustable compact cylinder featuring a unique mechanical stroke adjustment mechanism with positive locking. The dual-cushion design minimizes end-impact noise while maintaining positioning accuracy (±0.5mm repeatability). Includes corrosion-resistant chromium piston rod and anti-rotation guide for stable linear motion.
- Precision clamping fixtures in CNC machining centers
- Variable height positioning in automated assembly lines
- Material thickness compensation systems
- Packaging machine stopper adjustment mechanisms
- Semiconductor handling equipment
Installation note:
Adjust stroke length by loosening the lock nut and rotating the end stopper (1 full rotation = 2mm adjustment).
Lubricate piston rod weekly with ISO VG32 hydraulic oil in high-cycle applications.
| Property | Property Value |
|---|---|
| sku | SAUJ40X100-40 |
| Adjustable Stroke | <40mm> |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT1/4 |
| Magnet | Non-magnetic |
| Bore Diameter | <40mm> |
| Stroke | 100mm |
