Airtac SAUJ40 Adjustable Stroke Cylinder SAUJ40X100-50
2. Features custom bidirectional seal profile for piston sealing with compact dimensions and integrated oil reservoir;
3. Aluminum tube with octagonal pattern design, rodless construction. Enhanced corrosion resistance; Integrated external sensor mounting grooves for simplified installation;
4. Compared to ISO 15662 standard cylinders, SAU series demonstrates shorter stroke length at equivalent bore sizes;
5. Precision-engineered smooth cushioning adjustment mechanism;
6. Full compatibility with SC series cylinder mounting accessories;
7. High-temperature resistant sealing materials implemented, operational range: 0-150°C.
Category: Standard Cylinders | Brand: AirTAC | Series: SAUJ40
AirTAC SAUJ40X100-50 Adjustable Stroke Cylinder Specifications
- Model: SAUJ40X100-50
- Type: Double-acting adjustable stroke cylinder
- Bore size: 40mm
- Stroke length: 100mm (adjustable via external stopper)
- Operating pressure: 0.1–0.9 MPa
- Cushioning type: Adjustable elastic buffer (both ends)
- Mounting type: Standard MF1 flange (ISO 15552 compatible)
- Port size: M5x0.8 (G1/8 optional)
- Operating temperature: -20℃ to 80℃
- Piston material: Aluminum alloy with hard anodizing
- Rod material: Chrome-plated carbon steel
- Seal material: NBR (Nitrile rubber)
- Weight: 1.65 kg (with standard accessories)
- Dimensions: 220mm(L) × 70mm(W) × 70mm(H)
- Protection rating: IP40 (IP67 available with optional wiper)
- Lubrication: Pre-lubricated (Use ISO VG32 hydraulic oil)
Precision-engineered adjustable stroke cylinder featuring dual-position mechanical stoppers for millimeter-level stroke control. The hardened piston rod and wear-resistant seals enable 3,000km+ service life under standard conditions. Includes 3-position magnetic switch slots for position feedback integration.
- Variable position clamping in CNC fixtures
- Packaging line product height adjustment systems
- Automated assembly with multi-position requirements
- Semiconductor handling equipment
- Precision press brake tool positioning
Installation notes:
- Lock adjustment bolts with 1.2-1.5N·m torque after positioning
- Maintain 0.5mm minimum clearance between stoppers at full retraction
- Align stopper screws perpendicular to cylinder axis (±2° tolerance)
| Property | Property Value |
|---|---|
| sku | SAUJ40X100-50 |
| Adjustable Stroke | <50mm> |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT1/4 |
| Magnet | Non-magnetic |
| Bore Diameter | <40mm> |
| Stroke | 100mm |
