Airtac SAUJ40 Adjustable Stroke Cylinder SAUJ40X100-75
2. Features custom bidirectional seal profile for piston sealing with compact dimensions and integrated oil reservoir;
3. Aluminum tube with octagonal pattern design, rodless construction. Enhanced corrosion resistance; Integrated external sensor mounting grooves for simplified installation;
4. Compared to ISO 15662 standard cylinders, SAU series demonstrates shorter stroke length at equivalent bore sizes;
5. Precision-engineered smooth cushioning adjustment mechanism;
6. Full compatibility with SC series cylinder mounting accessories;
7. High-temperature resistant sealing materials implemented, operational range: 0-150°C.
Category: Standard Cylinders | Brand: AirTAC | Series: SAUJ40
AirTAC SAUJ40X100-75 Adjustable Stroke Cylinder Specifications
- Model: SAUJ40X100-75
- Bore size: 40mm
- Stroke: 100mm (adjustable range: 25-75% of full stroke)
- Operating pressure: 0.05-1.0 MPa
- Piston speed: 50-700mm/s
- Cushioning type: Adjustable elastic cushion (both ends)
- Mounting style: Basic type (MF1) with front/rear threaded mounting
- Port size: Rc1/8 (NPT1/8 optional)
- Ambient temperature: -20℃ to 80℃
- Lubrication: Pre-lubricated (Oil-free operation possible)
- Repeat positioning accuracy: ±0.5mm
- Rod material: Chrome-plated carbon steel (S45C)
- Tube material: Aluminum alloy (hard anodized)
- Weight: 1.85kg (with standard accessories)
- Dimensions:
- Extended length: 250mm
- Retracted length: 150mm
- Body width: 52mm
- Mounting height: 40mm
Precision-adjustable stroke cylinder featuring dual locking nuts for position retention, with visible stroke scale markings (1mm graduations). Incorporates wear-resistant guide bushings and integrated shock absorption. Compatible with magnetic sensors for position feedback (sensor groove included).
- Variable height work platforms in assembly lines
- Clamping force adjustment in CNC fixtures
- Material positioning in automated packaging systems
- Press tool depth control applications
- Semiconductor handling equipment stops
Installation note:
Locking nuts require 12-15N·m torque for secure fixation.
For vertical installations, use counterbalance valves when handling loads >5kg.
Adjust cushioning after final position setting.
| Property | Property Value |
|---|---|
| sku | SAUJ40X100-75 |
| Adjustable Stroke | 75mm |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT1/4 |
| Magnet | Non-magnetic |
| Bore Diameter | <40mm> |
| Stroke | 100mm |
