Airtac SAUJ40 Adjustable Stroke Cylinder SAUJ40X100-75S
2. Features custom bidirectional seal profile for piston sealing with compact dimensions and integrated oil reservoir;
3. Aluminum tube with octagonal pattern design, rodless construction. Enhanced corrosion resistance; Integrated external sensor mounting grooves for simplified installation;
4. Compared to ISO 15662 standard cylinders, SAU series demonstrates shorter stroke length at equivalent bore sizes;
5. Precision-engineered smooth cushioning adjustment mechanism;
6. Full compatibility with SC series cylinder mounting accessories;
7. High-temperature resistant sealing materials implemented, operational range: 0-150°C.
Category: Standard Cylinders | Brand: AirTAC | Series: SAUJ40
AirTAC SAUJ40 Adjustable Cylinder SAUJ40X100-75S Technical Details
- Model Code: SAUJ40X100-75S
- Series: SAUJ (Compact Adjustable Stroke)
- Bore Size: 40mm
- Stroke: 100mm (Adjustable Range: 25-100mm)
- Rod Diameter: 12mm
- Operating Pressure: 0.05-1.0 MPa
- Cushioning Type: Rubber Buffer + External Adjuster
- Mounting Style: Basic Type (No built-in mounts)
- Port Size: M5x0.8 (Standard) / NPT1/8 (Optional)
- Ambient Temperature: -10℃ to 60℃
- Piston Speed: 50-750 mm/s
- Material: Aluminum Barrel / Chrome-plated Rod
- Seal Type: NBR + PU Combination
- Weight: 1.8kg ±5%
- Dimensions (L×W×H): 250mm × 60mm × 60mm (Fully Extended)
Precision stroke-adjustable pneumatic cylinder featuring dual locking nuts for position fixation. The 75S suffix indicates special anti-rotation rod design with integrated guide slots. Optimized for repetitive positioning tasks requiring millimeter-level accuracy. Includes wear-resistant rod scraper for contamination control.
- PCB board clamping mechanisms
- Textile machine thread tension control
- Automated screwdriving tool height adjustment
- Glass panel polishing pressure regulation
- Semiconductor wafer handling systems
Installation Tip:
Apply Loctite 243 to adjustment threads during assembly. Lubricate with ISO VG32
pneumatic oil. Avoid side loads exceeding 15N. For vertical mounting,
use auxiliary rod support brackets (sold separately).
| Property | Property Value |
|---|---|
| sku | SAUJ40X100-75S |
| Adjustable Stroke | 75mm |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT1/4 |
| Magnet | S-Magnetic |
| Bore Diameter | <40mm> |
| Stroke | 100mm |
