Airtac SAUJ40 Adjustable Stroke Cylinder SAUJ40X1000-10
$148.64
Regular price
$156.14
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
SAUJ40X1000-10
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
1. Enterprise-standard cylinder compliant with internal specifications;
2. Features custom bidirectional seal profile for piston sealing with compact dimensions and integrated oil reservoir;
3. Aluminum tube with octagonal pattern design, rodless construction. Enhanced corrosion resistance; Integrated external sensor mounting grooves for simplified installation;
4. Compared to ISO 15662 standard cylinders, SAU series demonstrates shorter stroke length at equivalent bore sizes;
5. Precision-engineered smooth cushioning adjustment mechanism;
6. Full compatibility with SC series cylinder mounting accessories;
7. High-temperature resistant sealing materials implemented, operational range: 0-150°C.
Category: Standard Cylinders | Brand: AirTAC | Series: SAUJ40
Installation note:
Requires minimum 0.5mm/m alignment tolerance during mounting.
For full 1000mm stroke applications, ensure 1100mm clearance space.
Lubricate guide shafts monthly in high-cycle applications (>500,000 cycles/year).
2. Features custom bidirectional seal profile for piston sealing with compact dimensions and integrated oil reservoir;
3. Aluminum tube with octagonal pattern design, rodless construction. Enhanced corrosion resistance; Integrated external sensor mounting grooves for simplified installation;
4. Compared to ISO 15662 standard cylinders, SAU series demonstrates shorter stroke length at equivalent bore sizes;
5. Precision-engineered smooth cushioning adjustment mechanism;
6. Full compatibility with SC series cylinder mounting accessories;
7. High-temperature resistant sealing materials implemented, operational range: 0-150°C.
Category: Standard Cylinders | Brand: AirTAC | Series: SAUJ40
AirTAC SAUJ40X1000-10 Adjustable Cylinder Specifications
- Model: SAUJ40X1000-10
- Type: Double-acting adjustable stroke cylinder
- Bore size: 40mm
- Stroke: 1000mm (adjustable)
- Operating pressure: 0.1-0.9 MPa
- Cushioning: Adjustable pneumatic cushion at both ends
- Stroke adjustment: Mechanical stopper with locknut
- Mounting style: Basic type (no built-in mounts)
- Port size: G1/8 (NPT1/8 optional)
- Piston rod thread: M16×1.5
- Operating temperature: -20℃ to 80℃
- Material: Aluminum alloy barrel, hardened chrome-plated rod
- Seal material: NBR + Polyurethane combination
- Weight: 5.8 kg (with standard accessories)
- Dimensions: 1115mm(L) × 50mm(W) × 50mm(H) (fully extended)
- Rod end type: Female thread with pivot eye
- Max theoretical force: 1130N @0.5MPa
- Lubrication: Pre-lubricated (Oil-free operation possible)
High-precision long-stroke cylinder featuring micrometer-style stroke adjustment (±0.5mm repeatability). The hardened piston rod with multi-lip seals ensures minimal leakage during low-speed operations. Includes anti-rotation guide for stable linear motion in vertical installations.
Typical Applications:
- Palletizing robot end-effector positioning
- CNC machine tool clamping mechanisms
- Automotive assembly line lifting platforms
- Textile machinery tension control systems
- Solar panel cleaning robot actuators
Installation note:
Requires minimum 0.5mm/m alignment tolerance during mounting.
For full 1000mm stroke applications, ensure 1100mm clearance space.
Lubricate guide shafts monthly in high-cycle applications (>500,000 cycles/year).
| Property | Property Value |
|---|---|
| sku | SAUJ40X1000-10 |
| Adjustable Stroke | <10mm> |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT1/4 |
| Magnet | Non-magnetic |
| Bore Diameter | <40mm> |
| Stroke | <1000mm> |
