Airtac SAUJ40 Adjustable Stroke Cylinder SAUJ40X1000-100
2. Features custom bidirectional seal profile for piston sealing with compact dimensions and integrated oil reservoir;
3. Aluminum tube with octagonal pattern design, rodless construction. Enhanced corrosion resistance; Integrated external sensor mounting grooves for simplified installation;
4. Compared to ISO 15662 standard cylinders, SAU series demonstrates shorter stroke length at equivalent bore sizes;
5. Precision-engineered smooth cushioning adjustment mechanism;
6. Full compatibility with SC series cylinder mounting accessories;
7. High-temperature resistant sealing materials implemented, operational range: 0-150°C.
Category: Standard Cylinders | Brand: AirTAC | Series: SAUJ40
AirTAC SAUJ40X1000-100 Adjustable Cylinder Specifications
- Model: SAUJ40X1000-100
- Type: Adjustable stroke double-acting cylinder
- Bore size: 40mm (ISO 6432 standard)
- Stroke length: 1000mm (adjustable via mechanical stopper)
- Operating pressure: 0.1–0.9 MPa
- Cushioning type: Adjustable rubber buffer (both ends)
- Mounting style: Basic type (MF1) with adjustable mounting brackets
- Rod thread: M16×1.5 external thread
- Material: Aluminum alloy barrel, chrome-plated piston rod
- Seal material: NBR seals with wear-resistant ring
- Temperature range: -10℃ to 80℃
- Weight: 9.8kg (without accessories)
- Dimensions: 1120mm(L) × 50mm(W) × 50mm(H) (full extension)
- Port size: G1/8 (dual ports at both ends)
- Max thrust: 510N @0.63MPa
- Speed range: 50–800mm/s
- Protection rating: IP54 (standard wiper design)
High-precision long-stroke cylinder with position-lock mechanism, featuring dual adjustable stoppers (±5mm fine-tuning range) for millimeter-level positioning accuracy. The hardened stainless steel guide rod ensures stability during full extension. Includes anti-rotation design for vertical applications.
- Automated palletizing systems (box height adjustment)
- Plastic injection molding machine ejectors
- Textile machinery tension control units
- Solar panel cleaning robot arms
- Automotive assembly line positioning jigs
Installation note:
Requires rigid mounting surface (flatness ≤0.1mm/m) and alignment within 0.2° angular tolerance.
Lubricate with ISO VG32 hydraulic oil before initial operation. Avoid side loads exceeding 30N.
| Property | Property Value |
|---|---|
| sku | SAUJ40X1000-100 |
| Adjustable Stroke | 100mm |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT1/4 |
| Magnet | Non-magnetic |
| Bore Diameter | <40mm> |
| Stroke | <1000mm> |
