Airtac SAUJ40 Adjustable Stroke Cylinder SAUJ40X1000-10S
2. Features custom bidirectional seal profile for piston sealing with compact dimensions and integrated oil reservoir;
3. Aluminum tube with octagonal pattern design, rodless construction. Enhanced corrosion resistance; Integrated external sensor mounting grooves for simplified installation;
4. Compared to ISO 15662 standard cylinders, SAU series demonstrates shorter stroke length at equivalent bore sizes;
5. Precision-engineered smooth cushioning adjustment mechanism;
6. Full compatibility with SC series cylinder mounting accessories;
7. High-temperature resistant sealing materials implemented, operational range: 0-150°C.
Category: Standard Cylinders | Brand: AirTAC | Series: SAUJ40
AirTAC SAUJ40 Adjustable Stroke Cylinder SAUJ40X1000-10S Technical Specifications
- Model Code: SAUJ40X1000-10S
- Bore Size: 40mm (ISO 6432 standard)
- Stroke: 1000mm (adjustable with mechanical stopper)
- Operation Type: Double-acting
- Working Pressure: 0.05–0.8 MPa
- Piston Speed: 50–1000 mm/s (lubricated)
- Cushioning: Adjustable air cushion at both ends
- Port Size: 1/4" NPT (G1/8 optional)
- Mounting Style: Standard foot mounting (MF1) with reinforced base
- Rod Thread: M10×1.25 external thread
- Ambient Temperature: -20℃ to +80℃
- Seal Material: NBR (nitrile rubber) standard / FKM optional
- Weight: 5.8 kg ±3% (including mounting accessories)
- Dimensions: 1220mm(L) × 58mm(W) × 58mm(H) (fully extended)
- Rod End Type: Female clevis with Φ6 pin hole
- Repeat Positioning Accuracy: ±0.5mm
- ISO Certification: 6432, 15552, and VDMA 24562 compliant
High-precision adjustable stroke cylinder engineered for long-stroke automation applications requiring millimeter-level positioning control. Features dual chrome-plated piston rod (HCR coating) and aluminum alloy barrel with oxidation-resistant treatment. The 10S variant includes integrated shock absorbers and position locking screws for stable mid-stroke pauses.
- CNC machine tool clamping/unloading systems
- Automated warehouse vertical lift positioning
- Solar panel cleaning robot arm mechanisms
- Textile machinery tension control devices
- Automotive welding fixture stroke adjustment
Installation Guidelines:
Requires horizontal mounting alignment tolerance ≤0.2mm/m. Apply ISO VG32 hydraulic oil
lubrication when operating below -10℃. Maximum side load capacity: 35N at mid-stroke.
| Property | Property Value |
|---|---|
| sku | SAUJ40X1000-10S |
| Adjustable Stroke | <10mm> |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT1/4 |
| Magnet | S-Magnetic |
| Bore Diameter | <40mm> |
| Stroke | <1000mm> |
